PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink
PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink
PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink
PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink
PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink
PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink
PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink
PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink
PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink
PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink
Specifications
Brand Name :
Aquatrin
Model Number :
DXGF
Certification :
ISO CE SGS
Place of Origin :
China
MOQ :
1unit
Price :
USD15000-60000 1Set
Payment Terms :
T/T
Supply Ability :
10units per month
Delivery Time :
45days
Packaging Details :
wooden package
Type: :
Filling Machine
Warranty: :
2 years
Material: :
Stainless Steel SUS304
Product name: :
Carbonated Drink Filling Machine
Place of Origin: :
Jiangsu, China
Suitable for: :
Plastic bottle
Description
Product Description
March Expo soda drink making carbonated soft drink bottling machine
Bottle material: PET Bottle

Production capacity: 5000-7000bph We Can design specific product according to customers' demands We can supply complete filling line solution and filling machines for carbonated soft drinks
General descrption The suspending bottle-neck clamping design ensure whole production line more stable during the working process and it also avoids malfunctions caused by the different bottle thickness or height. The design also dramatically reduces the required quantities of interchange parts which make it more convenient to change different types of bottles on washing, filling and capping.
Magnetic torque is applied on bottle screw-capping.
Constant screw capping power can be adjustable steppless and therefore will not hurt the bottles at all.
Horizontal swirl cap sorting device is applied to avoid damaging caps. No caps, no capping; No caps, feeding system run
automatically.
Human-machine interface touch-screen and PLC control system are adopted on the machine.
Liquid level in the tank is controlled automatically. No bottles, no filling, no capping.
All parts connected with water are made of food grade stainless steel. All main components makers are world-known manufacturers

PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft DrinkPLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink

Technical Parameters

Model
CGFD8-8-3
CGFD12-12-6
CGFD18-18-6
CGFD 24-24-8
washing, filling and capping heads No.
8-8-3
12-12-6
18-18-6
24-24-8
Capacity
1500~2000BPH
3000~3500
4000~5000
6000~8000
Bottle Volume Range
volume=330-2000ml
φ=50-110 H=150~340mm volume=330-2500ml
Motor power(kw)
Main motor
Main motor 3.5kw
Main motor 4.0kw
Main motor 4.8kw
Overall dimensions (mm)
1.9kw
2450*1800*2400
2650*1900*2400
2900*2100 *2400
Weight (kg)
1900*1420*2000
2500
3500
4500
Model
CGFD 32-32-8
CGFD 40-40-10
CGFD 50-50-12
CGFD 60-60-15
washing, filling and capping heads No.
32-32-8
40-40-10
50-50-12
60-60-15
Capacity
8000-10000
10000-12000
12000-15000
15000-18000
Bottle Volume Range
volume=330-2000ml
φ=50-110 H=150 ~340mm volume=330-2500ml
Motor power(kw)
Main motor 7.6kw
Main motor 8.3kw
Main motor 9.6kw
Main motor 15Kw
Overall dimensions (mm)
4100*2000 *2400
4550*2650 *2400
5450*3210 *2400
5500*3510 *2400
Weight (kg)
6500
8500
9800
12000

PLC Carbonated Drink Filling Machine 1.9kw 7000bph For Soft Drink
