110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm
110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm
110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm
110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm
110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm
110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm
110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm
110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm
110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm
110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm
Specifications
Brand Name :
CHENXIN
Model Number :
CX-610
Certification :
ISO90001
Place of Origin :
CHINA
MOQ :
2/Set
Price :
Fob Shenzhen
Payment Terms :
T/T
Supply Ability :
500 sets per month
Delivery Time :
5-8 working days
Packaging Details :
boxes
stroke :
200mm
Stripping Wire φ :
50mm
Voltage :
AC 220v 50/60hz
Air pressure :
3-7kg/cm²
Cylinder φ :
100φ
Weight :
110kg
Dimension :
1,000mm*620mm*350mm
Description

CX-610 120 Square Wire Pneumatic Electronic Appliance Cable Wire Stripping Machine​

Suitable for the processing of the large wire diameter and long wire, such as 35 square, 50 square, 70 square, 95 square, 120 square wire

Features:

1 The oblique back design is ergonomic.

2 Double-acting cylinder, no spring break.

3 Exquisite knife molds, large and small machine types, and knife and molds are universal.

4 Unique sliding seat, light and agile, easy to work.

5 Adjustable structure, adjusted according to the thickness of the wire.

6 Adaptable wire: AC, DC power cord, computer wire, electronic wire, multi-core wire, special wire.

7 Stable sliding seat design, unique sliding seat design ensures more stable stroke and more precise cutting and stripping.

8 The foot pedal is easy to operate. Improved the traditional computer wire stripping method with feet and hands, and evolved into a front clamp back method, which saves energy and improves efficiency.

Technical Parameter:

Model CX-610 CX-600
Stroke 200mm 200mm
Stripping Wire φ Max.50mm Max.50mm
Voltage 110v/220V 60Hz 110v/220V 60Hz
Air pressure 3-7kg/cm² 3-7kg/cm²
Cylinder φ 100φ 100φ
Weight 110kg 150kg
Dimension(mm) 1,000*620*350 1750*620*470

110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm

Selected high-quality blades, using high-quality wear-resistant blades, durable and long-lasting sharpness

110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm

Air pressure regulating valve, cut off the gas, and open the gas regulating valve.

Function: When adjusting the machine, the air pressure can be turned off to prevent hand injury and play a protective role.

110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm 110kg Adjustable Pneumatic Wire Stripping Machine 1000mm*620mm*350mm
