1us Response 1000A Hall Effect Current Sensor EN50178
1us Response 1000A Hall Effect Current Sensor EN50178
Specifications
MOQ :
100
Payment Terms :
T/T
Delivery Time :
1-12 weeks
Packaging Details :
Original packing
Rated measuring current IPN :
1000A
Measuring range IPM :
±2100A
Power supply voltage VC :
DC±(15~24)×(1±10%)V
Current consumption IC (@±24V) :
≤±35mA+ISN
Rated measurement output ISN :
333.33mA
Turns ratio :
1:3000
Basic error δi(@IPN，TA=25℃) :
≤±0.4%
Linearity δL(@IPN，TA=25℃) :
≤±0.1%
Description

NACL-1000B-S5/SP1 current sensor

Product Details

product manual

NACL-1000B-S5/SP1 magnetic balance Hall current sensor is suitable for accurate measurement of AC, DC, and pulse current isolation. The primary side and the secondary side are completely insulated during measurement.

product advantages Applications Reference standard
High precision AC Inverter AC GB/T 25119-2010
EN50178
EN50155
Good linearity Private server motor drive
Low temperature drift Battery powered
Broadband Converter/Inverter
Quick response UPS/SVG

Main electrical parameters (@±IPN, TA = 25℃)
Rated measuring current IPN 1000A
Measuring range IPM ±2100A
Power supply voltage VC DC±(15~24)×(1±10%)V
Current consumption IC (@±24V) ≤±35mA+ISN
Rated measurement output ISN 333.33mA
Turns ratio 1:3000
Load resistance RM

@±15V, ±1000A:

0Ω~21Ω(70℃)

0Ω~19.5Ω(85℃)

@±15V, ±1500A:

0Ω~10Ω(70℃)

@±24V, ±1000A:

8.5Ω~48.5Ω(70℃)

10Ω~54Ω(85℃)

@±24V, ±2100A:

10Ω~14Ω(70℃)

Accuracy-dynamic parameters
Basic error δi(@IPN,TA=25℃) ≤±0.4%
Linearity δL(@IPN,TA=25℃) ≤±0.1%
Zero output current IO (@IP=0, TA = 25℃) ≤±0.5mA
Zero temperature drift IOT ≤±0.8mA
Response time
TR (90% of IPN&di/dt> 50 A/µS)		 ≤1µS

General data
Working temperature Ta -40~+85℃
Storage temperature Ts -45~+90℃
Weight m ≤850g

Insulation withstand voltage
Withstand voltage 3.8kV
