900A Current Transducers For DC Current Measurement
900A Current Transducers For DC Current Measurement
Specifications
MOQ :
100
Payment Terms :
T/T
Delivery Time :
1-12 weeks
Packaging Details :
Original packing
Maximum range :
200A~900A
Storage temperature :
-40 - 125
Output voltage (linear) :
Vout=(Uc/5)·(V0+G·Ip)
Zero output :
2.5
Current consumption :
13
Load Resistance :
10
Load capacitance :
1
Electrical zero offset :
±2.5
Description

NACA.XXXL-S6/SP5VA Current Transducers

Product Details

product manual

NACA XXXL-S6/SP5VA series current sensor is suitable for accurate measurement of AC, DC and pulse current isolation. The primary side and the secondary side are completely insulated during measurement.

Performance requirements
parameter name symbol unit parameter condition
Minimum Typical value Max
Electrical parameters
Maximum range IP A 200A~900A For more details, please contact CRRC
Storage temperature TS °C -40 125
voltage UC V 4.75 5 5.25
Output voltage (linear) Vout V Vout=(Uc/5)·(V0+G·Ip) @UC
Sensitivity G mV/A 2000/Ip @UC=5V
Zero output VO V 2.5 @UC=5V
Current consumption IC mA 13 15 @UC=5V, No load on Vout
Load Resistance RL KΩ 10
Load capacitance CL nF 1 10
Output internal resistance ROUT Ω 1 DC
Performance parameter
Zero output error X0 % ±0.65 @TA=25℃, UC=5V
±0.9 @-40℃<TA<125℃, UC=5V
Sensitivity error % ±2.25 @TA=25℃, UC=5V, 200A≤Ip≤800A
±2.5 @TA=25℃, UC=5V, Ip = 900A
±3.25 @-40℃<TA<125℃, UC=5V,200A≤Ip≤800A
±3.75 @-40℃<TA<125℃, UC=5V, Ip = 900A
Electrical zero offset FLY mV ±2.5
Magnetic zero offset FROM mV ±3
Proportional error .R % 0.5
Linearity error εL % -1 1 of full range
Response time tr μs 3
bandwidth BW kHz 40 @ -3dB
Phase difference ∆φ ° -4 @DC to 1kHz

Dimensions
Series size
900A Current Transducers For DC Current Measurement900A Current Transducers For DC Current Measurement

Mechanical parameters Remarks
● Plastic case PA 66 GF 25
● Magnetic core FeSi wound core
● Mass 50g

● 900A Current Transducers For DC Current Measurement

● VOUT>VO when IP flows in the positive direction (see arrow on drawing)
Electrical Interface
900A Current Transducers For DC Current Measurement

Procurement information

1. Products can be customized according to your needs. You are welcome to provide physical samples or detailed process drawings to design, produce and process.

2. If there is no special requirement, our company will assign logistics distribution and deliver the goods to customer factory

3. Payment method: delivery after payment, which can be negotiated according to the specific order quantity.

4. The response time of the number of customers should not exceed 8 working hours.

5. Emergency on-site service time shall not exceed 24 hours.

6. Provide emergency support for customer's urgent shortage of spare parts.
