Alpinesemi TVS Diode Array ALPAMDF20521CAL Automotive Multiline/Port Protection

Description:
The ALPAMDF20521CAL is AECQ101 approved ultra low capacitance transient voltage suppressor array, designed to protect automotive applications from the damaging effects of Electrostatic Discharge and Electrical Fast Transients.The ALPAMDF20521CAL meets IEC 61000-4-2 (ESD) and IEC 61000-4-4 (EFT) requirements. At higher operating frequencies or faster edge rates, insertion loss and signal integrity are a major concern. This device offers an ultra low capacitance and low leakage current in a miniature DFN-2- 0402 package

Alpinesemi TVS Diode Array ALPAMDF20521CAL Automotive High Efficiency

MILLIMETERS INCHES

OUTLINE DIMENSIONS
DIM MIN MAX MIN MAX
A 2.86 3.16 0.114 0.126
B 6.52 7.02 0.260 0.280
C 5.52 6.15 0.220 0.245
D 1.98 2.59 0.079 0.103
E 0.75 1.51 0.030 0.060
F 0.00 0.20 0.000 0.008
G 7.64 8.02 0.305 0.320
H 0.15 0.30 0.006 0.012
NOTES 1. Dimensions are exclusive of mold flash and metal burrs.
