0.5'' - 12'' Tri Clamp Silicone Gasket / Food Grade FKM Silicone Gasket Ring
0.5'' - 12'' Tri Clamp Silicone Gasket / Food Grade FKM Silicone Gasket Ring
0.5'' - 12'' Tri Clamp Silicone Gasket / Food Grade FKM Silicone Gasket Ring
0.5'' - 12'' Tri Clamp Silicone Gasket / Food Grade FKM Silicone Gasket Ring
Specifications
Certification :
ISO-9001:2000 system, ISO/TS 16949
Place of Origin :
Qingdao, China
MOQ :
500usd
Delivery Time :
30 Days
Packaging Details :
Neutural Packing or as customer's requirement
Material :
Food grade FKM; Silicone; EPDM etc
Shape :
Ring Gasket
Color :
Black or as you required
Size :
0.5'' to 12''
Mode of Production :
Compression/ Injection
Used :
Food,chemical,beverage
Description

Product Description

Product name 0.5'' to 12'' TC gaskets
Material Food grade EPDM,silicone,PTFE,NBR
Hardness 30~90 Shore A, as you required
Work Temperature -60 °C to 250 °C
Size 0.5'' to 12'' in stock
Color Black, clear, orange, or as your like
Production basis Samples or drawings
Property Chemical Resistance, Anti-Aging, Good Elasticity/ Flexibility, Excellent Oil Resistance, Excellent Seal Performance, and Good Buffer Action
Processing Mold Compression
Packing PE plastic bags then to the carton / as per your request
application fields It is used for food,beverage,pharmacy,chemical,dairy,cosmetics etc industries.
OEM/ODM OEM/ODM Service are available.Can design and produce variours Non-standard Rubber Parts according to your requirement.

Silicone:


Silicone's non-leechable high purity characteristics make it a #1 choice in many pharmaceutical and Bio-Pharm industry applications. With a wide temperature range of -58°F to 446°F, it's ideal for autoclaving and sanitizing repetitively in hand cleaning. Its flexibility is great even in ice-cream applications.
Temperature Range: -58°F to 446°F

EPDM:

Black EPDM offers good chemical resistance. An economical choice for water, acetone, or ketone applications.
Temperature Range: -65°F to 212°F

0.5'' - 12'' Tri Clamp Silicone Gasket / Food Grade FKM Silicone Gasket Ring

0.5'' - 12'' Tri Clamp Silicone Gasket / Food Grade FKM Silicone Gasket Ring

Main Rubber Compounds and Thermoplastic Elastomers

Material Working Temperature Property
NBR 40℃ ~ +120℃ Oil resistance Heat resistance(medium)
Low temperature resistance
ACM 20℃ ~ +150℃

Oil resistance

Good heat resistance
FKM 30℃ ~ +200℃

Oil resistance

High temperature resistance
Chemicals
HNBR -40℃ ~ +170℃ Oil resistance
High temperature resistance
Chemicals resistance
Low temperature resistance
VMQ(Silicone) -50°C ~ +230°C lammability ,low gas permeability and excellent resistance to ozone,weathering and aging.
EPDM -50~ +150 °C EPDM shows good heat ,ozone and aging resistance ,in addition they also exhibit high levels of elasticity, good low temperature behavior as well as good insulating properties.

Our service

  1. OEM and OEM service provided, produce as customer's drawing or samples.
  2. Competitive prices,high quality,best delivery time and best service.
  3. TKS can offer the best design, sample, production of any speciation our customer requires.
  4. TKS can offer the best Rubber Compounds and Thermoplastic Elastomers, whichever our customer requires.
  5. All products are 100% inspected before shipment !
  6. Installation guide.
  7. Reply within 24 hours

FAQ

1. How to produce ?

we can produce according to seal type and sizes .
if you need some customized parts, we can produce according to drawing and samples.

2How to make the order?

You can send us email or inquiry at alibaba directly.

3. What is your main market?

Our main market is north America, UK, Australia, Middle East , Europe.

4.Do you provide samples ? is it free or extra

We can supply you free samples without extra charges, but express cost is for buyer's account.

5.How is the quality?

Strict control when production, 100% inspection before shipment.

6.Do you provide samples ? is it free or extra ?


Yes,with batch order we could offer the sample for free charge but do not pay the cost of freight.
