Oil Resistance Die Cut Molded Rubber Parts For Industrial Machine Various Color
Oil Resistance Die Cut Molded Rubber Parts For Industrial Machine Various Color
Oil Resistance Die Cut Molded Rubber Parts For Industrial Machine Various Color
Oil Resistance Die Cut Molded Rubber Parts For Industrial Machine Various Color
Specifications
Certification :
ISO-9001:2000 system, ISO/TS 16949
Place of Origin :
Qingdao, China
MOQ :
500usd
Delivery Time :
30 days
Packaging Details :
Neutural Packing
Material :
Nitrile Rubber,NR,EPDM,SILICONE,,Neoprene,SBR,HNBR,ACM,etc.
Size :
customized
Color :
black or any other color you required
Item :
rubber seal ring
Feature :
Durable,anti-statistic, high-low temperature
Product name :
round ring rubber parts
Description

Die Cut Molded Rubber Parts, molded rubber parts, Customized Mold Cutting Black NBR Rubber Parts

Product Description

Product name round rubber seal ring
Material EPDM, NBR, FKM, PU, SILICONE, HNBR, ACM, etc. Wide range of material is available.
Hardness 20 degree ~ 90 degree
Color black or any color you want
Temperature -60°C to+300°C
Size as customer's drawing or samples
Feature

1. Ozone and Chemical resistance
2. Anti-aging,good flexibility ,good elasticity
3. Excellent oil resistance
Package Inner plastic bag/outside carton
Application automobile, industrial machine & equipment, house-hold appliance, etc





Oil Resistance Die Cut Molded Rubber Parts For Industrial Machine Various Color

Oil Resistance Die Cut Molded Rubber Parts For Industrial Machine Various Color




Rubber specification

hysical and mechanical properties of the rubber material

NBR NBR NBR NBR ACM FKM FKM MVQ
Normal condition Hardness (shoreA) 60±5 70±5 80±5 84~ 93 70±5 70±5 84~ 93 70±5
Tensile
strength(Min)MPa		 9 11 11 10 6 10 11 3.5
Elongation(Min) 300 220 150 100 80 150 100 60
Hot air ageing Condition(℃×h) 125×24 125×24 125×24 125×24 150×24 200×24 200×24 230×24
Hardness
change(max)		 +10 +10 +10 +10 +10 0～+10 0～+10 +10
Change of tensile
strength(max)%		 -15 -15 -20 -20 -40 -20 -20 -5
Change of
elongation(max)%		 -40 -35 -35 -40 -50 -30 -30 -25
Compression
Permanent
Set		 Condition(℃×h)
Max%		 125×22 125×22 125×22 125×22 150×22 200×22 200×22 175×22
50 50 50 50 70 50 50 30
Fluid
resista
nt
test		 ASTM
Oil
No.1		 Condition(℃×h) 125×24 125×24 125×24 125×24 150×70 150×24 150×24 175×70
Hardness
change(max)		 5～+10 5～+10 5～+10 5～+10 5～+10 5～+5
Change of tensile
strength(max)%		 -30 -20
Change of
elongation(max)%		 -40 -20
Change of volume% -12~+15 -10~+15 -10~+5 -10~+5 5～+5 -3~+5 -3~+5 0~+10
ASTM
Oil
No.3		 Condition(℃×h) 125×24 125×24 125×24 125×24 170×70 150×24 150×24
Hardness
change(max)		 -15 ~ 0 -15 ~ 0 -15 ~ 0 -15 ~ 0 -25 ~ 0
Change of tensile
strength(max)%		 -40
Change of
elongation(max)%		 -40
Change of volume % 0～+20 0～+20 0～+20 0～+20 0～+45 -0～+15 -0+15
Brittleness temperature ℃ -25 -25 -25 -25 -20 -25 -15 -70

Our Advantages

1. Available material: NBR, HNBR, EPDM, ACM, Silicone, (FKM), etc. Wide range of material is available.
2. All manufacturing processes confirm to the ISO-9001:2000 system, ISO/TS 16949.
3. Excellent chemical and physical property, excellent in oil resistant, high/low temperature-resistant, wearing-resistant, oil-resistant, dust-resistant.
4. Custom: design and manufacture complete sets of rubber parts based on customer's requirements, any specification is welcome according to your requirements.
5. Available in various sizes and colors.
6. State standard and non-state standard sizes available.
