Specifications
Brand Name :
ROTYPACK
Model Number :
RTL420
Certification :
CE
Place of Origin :
CHINA
MOQ :
1SET
Price :
USD4500.00~6000.00/SET
Supply Ability :
12 SETS
Delivery Time :
30DAYS
Packaging Details :
WOODEN CASE
Packing speed :
30-60bag/min
Maxing filling :
1200ml
Noise index :
<75dB
Voltage :
220V 50HZ
Power :
3.0kW
Material :
SUS304
Description

RT420L Vertical Pouch Nuts Packaging Machine 500g Nuts Pouch Packing 1kg Corn Pouch Packing

PICTURE FOR REFERENCE

30-60bag/min Vertical Pouch Packing Machine 3.0kW max 1000mL Automatic stop function

Packing specification

Rtl-420: the measuring range of a single bag is within 1200mL

2.1 Multilayer composite film of packaging materials

2.2 Packaging products can be packaged with different cutting devices

2.3 Packaging Speed RTL-420 Packaging speed: 30-60 packs/min

2.4 Packing accuracy ±1%

The characteristics :

High quality packaging and minimal product loss,

Perfect packaging appearance.

Easy upgrade of main machine

Good working environment.

Product feature:
1. Efficient: Bag - making, filling, sealing, cutting, heating, date / lot number achieved in one time;
2. Intelligent: Packing speed and bag length can be set through the screen without part changes;
3. Profession: Independent temperature controller with heat balance enables different packing materials;
4. Characteristic: Automatic stop function, with safe operation and saving the film;
5. Convenient: Low loss, labor saving, easy for operation and maintenance;
6. Weighing accuracy 0.2 to 1.0 gram.

Technical parameters:

Packing speed: 30-60bag/min
Bag-making size : (L)80-280mm (W)80-200mm
Metering range: 1000mL (maximum)
The maximum packaging film width is 400mm
The film thickness : 0.04-0.09mm
Gas consumption: 0.8 Mps 0.6m3/min
Total power/voltage: 3.0kW 220V 50HZ
Dimensions: L1350mm*W1100mm*H1620mm
The weight: 420kg

Electrical parts:

NO. NAME BRAND FUNCATION
1 Servo motor CHINA INOVANCE PULLING
2 Temp control Korea Autonics Temp control
3 GPG motor CHINA TAIBANG Transport control
4 PLC CHINA INOVANCE Program control
5 Touch screen CHINA INOVANCE
6 Sensor CHINA BDL BAG CHECK

30-60bag/min Vertical Pouch Packing Machine 3.0kW max 1000mL Automatic stop function30-60bag/min Vertical Pouch Packing Machine 3.0kW max 1000mL Automatic stop function30-60bag/min Vertical Pouch Packing Machine 3.0kW max 1000mL Automatic stop function

Packaging & Shipping

International stardard wooden box packinage machine

Rutian provides professional packaging and logistics services for you.With rich experience and careful preparation.We ensure that
the machine is delivered to you safely and soundly
