RTL-620 High Speed Automatic Vertical Granule Candy Sachet Filling and Packing Machine

Packing specification

Rtl-420: the measuring range of a single bag is within 1200mL

2.1 Multilayer composite film of packaging materials

2.2 Packaging products can be packaged with different cutting devices

2.3 Packaging Speed RTL-420 Packaging speed: 30-60 packs/min

2.4 Packing accuracy ±1%

Characteristics :

High quality packaging and minimal product loss,

Perfect packaging appearance.

Easy upgrade of main machine

Good working environment.

Details of features:

Equipped with safety protection, in line with the requirements of enterprise safety management.

2. Intelligent temperature controller is adopted to ensure accurate temperature control, beautiful and smooth sealing.

3. PLC system and super large display touch screen constitute the driving control core, which maximizes the control accuracy, reliability and intelligence of the whole machine.

4. The machine and metering configuration can automatically complete the metering, feeding, bag filling, date printing, gas (exhaust), finished product delivery of all the packaging process, and automatically complete the counting.

5. The touch screen can store a variety of packaging process parameters of different products, which can be used at any time when changing products without resetting.

6. There is a fault display system to help troubleshoot the fault in time.

7. It can be made into pillow bags and punch hole bags according to customers' needs.

8. The packing material loss is low. The machine USES prefabricated packaging bags with perfect packaging pattern and good sealing quality, thus improving the product grade.

Technical parameters:

Packing speed: 30-60bag/min

Bag-making size :(L)80-300mm (W)80-200mm

Pillow bag, vertical bag, punch device

Metering range: 1200mL (maximum)

The maximum packaging film width is 400mm

The film thickness : 0.04-0.09mm

Gas consumption: 0.8 Mps 0.6m3/min

Total power/voltage: 3.0kW 220V 50HZ

Dimensions: L1450mm*W1100mm*H1400mm

The weight: 520kg

Electrical parts:

Our company, Shanghai Rutian Packaging Co., Ltd. has many years of service experience in food, pharmaceutical, chemical, edible oil and other industries. And China's largest dairy company Yili, Nestle, other food companies has cooperated with us. Our main service team has many years of working experience.The company's position in the Chinese market is to provide high quality and high grade equipment for our customer.Our company is one of the top five packaging companies in China. Our factory covers an area of 5000 square meters and has more than 80 employees. We have been engaged in researching and producing packing machines for many years

Real Picture in the workshop
