Specifications
Brand Name :
Yating
Model Number :
YTMGCF60x20x2
Certification :
ISO
Place of Origin :
Wuhan
MOQ :
1set
Price :
negotiated
Payment Terms :
T/T, Western Union
Supply Ability :
50set/month
Delivery Time :
7-15days
Packaging Details :
polybag+wooden case
Condition :
New
Application :
paddy
Warranty :
one year
Name :
Paddy separator machine,Paddy separator
Function :
separate paddy rice and brown rice
Feature :
Easy Operation, High Yield, Convenient Maintenance
Description

MGCF Gravity Paddy Separator Machine with Double Body for Paddy and Brown Rice

Description:
Professional grain cleaning equipment,according to the requirements of rice milling process of each user, the two sieves can be used in parallel or in series.It is specially used for removing high impurity content and complex miscellaneous conditions materials.Widely used in soybeans, beans, corn, wheat, seeds, sesame and other cereals and all kinds of grains.

Characteristic:
1. Stable performance because the equipment has a constant separation function, so the separation effect is stable in the working process.
2. The unique transmission device of this product is effectively improved on the basis of the existing domestic production of the double sieve body grain coarse screen, and the load capacity and connecting rod bearing of this machine are strengthened, which exceeds the domestic standard, so as to extend the service life.
3. More reasonable material distribution function: due to the fact that the current domestic similar products generally have narrow feeding surface, too steep cutting corner and other phenomena, the feeding surface is widened, and the cutting corner turns into two angles of feeding, so as to make the material distribution unobstructed.
4. Equipped with automatic control device, the equipment will start automatically when the material is lowered. Once the material hopper becomes empty, the double grain rough separation screen will stop working automatically to keep the current situation of the material on the screen surface. After the material is received, it can be adjusted within 0-99 degrees, and it will start automatically and work normally.
5. Excellent separation function and special design make this machine adapt to all kinds of rice processing, that is, it can separate long material from long grain and short material from brown rice.

Model YTMGCF60x20x2 YTMGCF46x20x2
Layers of Separating Plate 20x2 20x2
Output of Pure Brown Rice 6.5-7.5t/h 4.5-6.0t/h
Grain Contented In Pure Brown Rice ≤5(grain/kg) ≤5(grain/kg)
Re-hulls Contain Brown Rice ≤10% ≤10%
Volume of Re-hulling and Pure Brown Rice About 15% About 15%
Suction Volume of Dedusting 170×2(m3/h) 170×2(m3/h)
Rotational Speed of Spindle 300±5rpm 300±5rpm
Sieve Surface Size(LxW) 1300x600(mm) 1300x600(mm)
Weight 1350kg 1150kg
Power 3kw 2.2kw
Overall LxWxH(mm) 2490x1840x2200 2140x1740x2100
Note: The above technical data can be changed without notice.

To learn more about this machine, please visit: www.riceprocessingplant.com,and our facebook page.

If you have any questions,please feel free to contact us.
