380V 50Hz Home Rice Polishing Machine Horiztontal Type Mist Polisher 3-5 Ton Per Hour
380V 50Hz Home Rice Polishing Machine Horiztontal Type Mist Polisher 3-5 Ton Per Hour
Specifications
Brand Name :
Yating
Model Number :
YTPG150Z/160Z
Certification :
ISO
Place of Origin :
Wuhan
MOQ :
1set
Price :
negotiated
Payment Terms :
T/T, Western Union
Supply Ability :
50sets per month
Delivery Time :
10-20days
Packaging Details :
polybag+wooden case
Warranty :
One Year
Application :
White Rice Processing, Parboiled rice Processing, Home USe
Voltage :
380V, 50Hz
Function :
rice grinding and rice polishing
Type :
Rice Processing machine, Grain Processing Equipment
Name :
Rice grinding machine ,rice polisher,rice polishing machine
Description

3-5ton per hour Rice Polishing Machine ,Horiztontal Type Mist Polisher

Operating Principle:

This polishing unit uses twice spray moistening polishing, the coming-out water is atomized through nozzles at first, and enters the polishing chamber evenly from main shaft hole at feeding end. Under a strong aspiration, rice rubs with screen plate and rotating smooth stainless steel roll each other. Under combined hydrothermal and friction effect, residual bran and groove mark are removed from rice surface, so as to form a gelatinous layer of starch on rice grain surface. At the same time, a secondary moistening is carried out in main shaft hole at material discharging end through hydraulic nozzles, to make rice surface sparkling and bright, smooth and clean, so as to improve the grades and commercial value of rice. The gelatinous layer can also improve the oxidation resistance and prolong the fresh-keeping period of rice. At the same time, rice with smooth and clean surface can not be washed or can be washed in a little, so that the rice nutrients will be lost very little, its taste is floppy and flavorful, and its edible value is increased.
This polishing unit can be used together with a rice whitener and also used alone for rice further processing.

Item Unit YTPG150Z/YTPG160Z
Capacity Kg/h 3000-5000/3500-5500
Main Axial Speed r/min 700
Polishing Roller mm Φ170x1550
Spiral Propeller mm Φ190x359(dia*length)
Radial Trapped Gas mm 12.5
Axial Feed End Trapped Gas mm 2
Axial Discharge End Trapped mm 10
Weight kg 1800
Air Volume m3/h 3500-5500/4500-5500
Static Pressure(water column) mm 220-280
Power kw 55(4 grade)
Overall(LxWxH) mm 2500x950x2250/2550x960x2250
Note: The above technical data can be changed without notice.

To learn more about this machine, please visit: www.riceprocessingplant.com,and our facebook page.

If you have any questions,please feel free to contact us.
