30-500TPD Wheat Flour Mill Machine and Combined Flour Mill Equipment

Flour mill equipment is widely used in various cereals, such as corn, rice, wheat, soybeans, peanuts, etc. The output of combined equipment is generally more than one ton per hour. The flour mill production line can be configured according to the mesh and quality level of flour.

Select Wuhan Yating Machinery Co.,Ltd as the partner, the company's technical personnel can help customers to provide detailed solutions including: equipment selection, plant construction, detailed quotation, etc. through demand understanding, field investigation, etc

Main Technical Parameters of 30Tons Flour Unit:

1. Yield: 30tons of wheat flour per day

2. Main Equipment

(1) Cyclone for Powder

Grain cleaning equipment: efficient combination grain cleaning machine, wheat washing machine

Grinding equipment: grinding machine, powder lifter

Other auxiliary equipment and accessories

(2) Flat Screen Powder Extraction

Grain cleaning equipment: high efficiency combined grain cleaning machine, magnetic separator, wheat washing machine

Milling equipment: milling machine, double bin flat screen, bran brush machine

Other auxiliary equipment and accessories

3. Workshop Size of 30Tons Flour Unit

Cyclone for powder: 12m long, 7m wide and 4.5m high

Lifting powder by flat screen: 13m long, 8m wide and 4.5m high

4. Power For 30Tons Flour Unit

Cyclone for powder: 64KW

Powder extraction by flat screen: 74kw

5. Product Category

Special and grade 1 super powder: 65%

Grade 2 super powder: 75%

Standard powder: 80%

Inferior powder: 5-15%

Bran: 20%

Machine Installation: we can dispatch engineer for installing and commissioning based on customer requirement.Engineer’s Visa,round trip air ticket,local transport,local accommodation and food,daily salary USD100/person/8hours is covered by customer side.

Warrantee: one year start from the day of the acceptance for running machine at final customer side.
