Convenient Grain Bin Dryer Mini Dryer For Rice Mill 10-15 Ton Per Batch
Convenient Grain Bin Dryer Mini Dryer For Rice Mill 10-15 Ton Per Batch
Convenient Grain Bin Dryer Mini Dryer For Rice Mill 10-15 Ton Per Batch
Convenient Grain Bin Dryer Mini Dryer For Rice Mill 10-15 Ton Per Batch
Convenient Grain Bin Dryer Mini Dryer For Rice Mill 10-15 Ton Per Batch
Convenient Grain Bin Dryer Mini Dryer For Rice Mill 10-15 Ton Per Batch
Specifications
Brand Name :
Yating
Model Number :
YTGD10/YTGD12/YTGD15
Certification :
ISO
Place of Origin :
Wuhan
MOQ :
1set
Price :
negotiated
Payment Terms :
T/T, Western Union
Supply Ability :
50set/month
Delivery Time :
7-15days
Packaging Details :
polybag+wooden case
Capacity :
10-15tons per batch
Application :
paddy,rice,wheat,corn,maize,bean,seed,
Warranty :
one year
Name :
tower grain dryer,batch grain dryer,paddy grain dryer,grain dryer machine
Function :
grain drying machine
Feature :
Easy Operation, High Yield, Convenient Maintenance
Description

10-15ton per Batch Grain Dryer,Rice Grain Dryer Machine,Paddy Grain Dryer

Features:

1. Charging and discharging grain in the top: cancel the top auger, use direct flow the grain to the dryer structure, to avoid mechanical failure, lower power and reduce the paddy crack rate.

2. Crosswise eight groove drying technology: Thin layer drying,the drying cost down 20% and improve drying efficiency more than 15%.

Technical Specifications of 10T/12T/15T Grain Dryers
Model YTGD10 YTGD12 YTGD15
Type Batch type circulation(non continuance)
Volume(t) Paddy(560kg/m3) 10 12 15
Wheat(680kg/m3) 11.5 13.5 16.5
Outer Dimension(mm) LxWxH 4750x2472x8460 4750x2472x9460 4750x2472x10460
Handling Capacity (kg/h) (range of moisture reduction from 25% to 14.5%) 700-1000
Husk Burner Type Gun type,high voltage spray
Ignition Mode Automatic high voltage ignition
Husk Consumption(kg/h) 8-16
Fuel Hig clean kerosene or High clean 0# diesel
Blower Motor Power (kw) 5.5
The Total Power of Motor(kw)/ Voltage(v) 7.75/380
Time of Feeding(min) Paddy 60～74 77-84 87-94
Wheat 63～70 73-80 83-90
Time of Discharging(min) Paddy 60～68 70-78 80-88
Wheat 56～58 66-78 76-88
Moisture Reduction Rate Per Hour Paddy 0.4～0.8％
Wheat 0.4～1.0%
Automatic Control and Safety Device Automatic moisture meter, automatic ignition, automatic stop, temperature control device, fault alarm device, full grain alarm device, electrical overload protection device, leakage protection device
The moisture reduction rate listed above is reference value. Effected by the air temperature outside, relative humidity, the variety of drying and so on, the actual value will be a little different.No notice will be given if there is a change for specification, dimension and color.

To learn more about this machine, please visit: www.riceprocessingplant.com,and our facebook page.

If you have any questions,please feel free to contact us.
