Tank brand is a high-end luxury off-road SUV brand launched by Great Wall Motor, which takes "Iron Man Tenderness" as the brand proposition to open a new category market.
Tank 500 is the first mass-produced model of business luxury series of Tank brand, positioned as medium and large luxury off-road SUV.
TANK 500 2023 3.0T sport Dengfeng model 5 seats | TANK 500 2023 3.0T Shangwu Zaojing model 7 seats | TANK 500 2022 3.0T HIGH END CUSTOM model 5 seats | |
Basic configuration | |||
Car class | Middle-large size | Middle-large size | Middle-large size |
Energy Type | Gasoline+48v light mixed system | Gasoline+48v light mixed system | Gasoline+48v light mixed system |
Market issue time | 2023.03 | 2023.03 | 2022.03 |
Max power(kw) | 265 | 265 | 265 |
Max torch(Nm) | 500 | 500 | 500 |
Engine | 3.0T 360HP V6 | 3.0T 360HP V6 | 3.0T 360HP V6 |
gearbox | 9-speed automatic manual transmission | 9-speed automatic manual transmission | 9-speed automatic manual transmission |
L*W*H(mm) | 5070*1934*1905 | 4878*1934*1905 | 4878*1934*1905 |
Body structure | 5 door 5 seats SUV | 5 door 7 seats SUV | 5 door 5 seats SUV |
Maximum speed (km/h) | 180 | 180 | 180 |
Official 0-100km/h acceleration (s) | - | - | - |
WLTC comprehensive fuel consumption (L/100KM) | 11.19 | 11.79 | 10.79 |
Car Body | |||
Longth(mm) | 5070 | 4878 | 4878 |
width(mm) | 1934 | 1934 | 1934 |
height(mm) | 1905 | 1905 | 1905 |
wheel base(mm) | 2850 | 2850 | 2850 |
front wheel base(mm) | 1635 | 1635 | 1635 |
rear wheel base(mm) | 1635 | 1635 | 1635 |
full load minimum space from floor(mm) | 224 | 224 | 224 |
approach angle (°) | 29.6 | 29.6 | 29.6 |
departure angle (°) | 24 | 24 | 24 |
Car Structure | SUV | SUV | SUV |
door opening method | flat open | flat open | flat open |
Number of doors (PC) | 5 | 5 | 5 |
Number of seats (PC) | 5 | 7 | 5 |
Fuel tank volume (L) | 80 | 80 | 80 |
Trunk volume (L) | - | - | - |
Curb weight (KG) | 2475 | 2565 | 2455 |
Total mass of quasi-towing trailer (KG) | 2500 | 2500 | 2500 |
Maximum full load mass (KG) | 3090 | 3090 | 3090 |
Engine | |||
Engine model | E30Z | E30Z | E30Z |
Displacement (mL) | 2993 | 2993 | 2993 |
Displacement (L) | 3 | 3 | 3 |
Intake form | Turbo charged | Turbo charged | Turbo charged |
engine layout | Vertical | Vertical | Vertical |
Cylinder arrangement | V | V | V |
Number of cylinders (pcs) | 6 | 6 | 6 |
Valves per cylinder (PC) | 4 | 4 | 4 |
Air distribution structure | DOHC | DOHC | DOHC |
Maximum horsepower (Ps) | 360 | 360 | 360 |
Maximum power (KW) | 265 | 265 | 265 |
Maximum power speed (rpm) | 6000 | 6000 | 6000 |
Maximum torque (NM) | 250 | 250 | 250 |
Maximum Torque(N/M) | 500 | 500 | 500 |
Maximum torque speed (rpm) | 1500-4500 | 1500-4500 | 1500-4500 |
Maximum Net Power (kW) | 260 | 260 | 260 |
fuel form | Gasoline+48v light mixed system | Gasoline+48v light mixed system | Gasoline+48v light mixed system |
fuel label | 95 | 95 | 95 |
Oil supply method | Mixed injection | Mixed injection | Mixed injection |
cylinder head material | Aluminum alloy | Aluminum alloy | Aluminum alloy |
Cylinder material | Aluminum alloy | Aluminum alloy | Aluminum alloy |
Environmental Standards | China VI | China VI | China VI |
Gearbox | |||
Number of gears | 9 | 9 | 9 |
Type of gearbox | AT | AT | AT |
Short name | 9-speed automatic manual transmission | 9-speed automatic manual transmission | 9-speed automatic manual transmission |
Chassis steering | |||
drive mode | Front four-wheel drive | Front four-wheel drive | Front four-wheel drive |
Four-wheel drive | Timely four-wheel drive | Timely four-wheel drive | Timely four-wheel drive |
center differential structure | multiple-plate clutch | multiple-plate clutch | multiple-plate clutch |
Front suspension type | Double wishbone independent suspension | Double wishbone independent suspension | Double wishbone independent suspension |
rear suspension type | Integral axle non independent suspension | Integral axle non independent suspension | Integral axle non independent suspension |
Assisted type | Electric assist | Electric assist | Electric assist |
Body structure | Non-bearing type | Non-bearing type | Non-bearing type |
wheel braking | |||
Front brake type | ventilated disc | ventilated disc | ventilated disc |
rear brake type | ventilated disc | ventilated disc | ventilated disc |
Parking brake type | Electronic parking | Electronic parking | Electronic parking |
Front tire specification | 265/60 R18 | 265/55 R19 | 265/50 R20 |
rear tire specification | 265/60 R18 | 265/55 R19 | 265/50 R20 |
Spare tire specification | All full size | All full size | All full size |
Active/passive safety equipment | |||
Main/passenger airbags | Driver● /Vice driver ● | Driver● /Vice driver ● | Driver● /Vice driver ● |
Front/rear side airbags | Front● /Rear - | Front● /Rear - | Front● /Rear - |
Front/rear head airbags (curtain) | Front● /Rear● | Front● /Rear● | Front● /Rear● |
Knee airbag | - | - | - |
pedestrain auto protect | - | - | - |
Tire pressure monitoring function | Tire pressure alarm | Tire pressure alarm | Tire pressure alarm |
Seat belt reminder | All car | ●front ●second row | All car |
ISOFIX child seat interface | ● | ● | ● |
ABS anti-lock | ● | ● | ● |
Brake force distribution (EBD/CBC) | ● | ● | ● |
Brake Assist (EBA/BAS/BA) | ● | ● | ● |
Traction Control(ASR/TCS/TRC) | ● | ● | ● |
Car steadiness control (ESC/ESP/DSC) | ● | ● | ● |
Parallel Auxiliary | ● | ● | ● |
Lane Departure Warning System | ● | ● | ● |
Lane Keeping Assist | ● | ● | ● |
Lane centered keeping | ● | ● | ● |
Active Braking/Active Safety System | ● | ● | ● |
Road Traffic Sign Recognition | ● | ● | ● |
DOW open door warning | ● | ● | ● |
front collision warning | ● | ● | ● |
Fatigue driving alarm | ● | ● | ● |
Forward Collision Warning | ● | ● | ● |
Assist/Control configuration | |||
Front/rear parking radar | Front●/Rear ● | Front ●/Rear ● | Front●/Rear ● |
driving assistance video | ● 360 degree panoramic image | ● 360 degree panoramic image | ● 360 degree panoramic image |
Transparent chassis/540-degree video | ● | ● | ● |
Reversing side warning system | - | ● | ● |
cruise system | ●Full speed adaptive | ●Full speed adaptive | ●Full speed adaptive |
Driving mode switching | ●sports ●economy ●standard/comfortable ●cross-country ●snowfield | ●sports ●economy ●standard/comfortable ●cross-country ●snowfield | ●sports ●economy ●standard/comfortable ●cross-country ●snowfield |
automatic parking | - | ● | ● |
Remote control parking | - | ● | ● |
hill assist | - | - | ● |
steep descent | ● | ● | ● |
Changable suspension | - | - | ●Suspension soft and hard adjustment |
air suspension | - | - | - |
Electromagnetic induction suspension | - | - | - |
Variable steering ratio | - | - | - |
Central differential locking function | ● | ● | ● |
Integrated active steering system | - | - | - |
Limited slip differential/differential lock | ○Front axle differential lock ●Rear axle differential lock | ○Front axle differential lock ●Rear axle differential lock | ○Front axle differential lock ●Rear axle differential lock |
Low speed four-wheel drive | ● | ● | ● |
Peristaltic mode | ● | ● | ● |
Tank turning | ● | ● | ● |
Assisted driving level | L2 | L2 | L2 |
Assisted driving level | - | L2 | - |
External / Anti-Theft Configuration | |||
sunroof type | Electric sunroof | Panoramic opening sunroof | Panoramic opening sunroof |
Sport Appearance Kit | - | - | - |
Rim material | Aluminum Alloy | Aluminum Alloy | Aluminum Alloy |
Electric closing door | - | - | - |
Electric trunk | - | - | - |
Induction trunk | - | - | - |
Inductive trunk position memory | - | - | - |
roof rack | ● | ● | ● |
Engine electronic immobilizer | ● | ● | ● |
interior central lock | ● | ● | ● |
key type | ●Remote Key ●Bluetooth key | ●Remote Key ●Bluetooth key | ●Remote Key ●Bluetooth key |
keyless start system | ● | ● | ● |
Keyless entry function | front row | front row | front row |
remote start function | ● | ● | ● |
Side pedal | ●electric | ●electric | ●electric |
Internal configuration | |||
Steering wheel material | Leather | Leather | Leather |
Steering wheel position adjustment | ● Manual up and down + front and rear adjustment | ● Manual up and down + front and rear adjustment | ● Manual up and down + front and rear adjustment |
Shift form | ●Electrical gear shift | ●Electrical gear shift | ●Electrical gear shift |
Multifunction steering wheel | ● | ● | ● |
steering wheel shift | ● | ● | ● |
Steering wheel heating | ● | ● | ● |
Trip computer display screen | ●colourful | ●colourful | ●colourful |
Full LCD Dashboard | ● | ● | ● |
LCD meter size | ●12.3" | ●12.3" | ●12.3" |
HUD | - | ● | ● |
built in recorder | ● | ● | ● |
auto reduce noise | ● | ● | ● |
wireless charger | ●Front row | ●Front row | ●Front row ●Rear row |
ETC device | ● | ● | ○ |
Seat configuration | |||
seat material | ●imitation leather | ●Genuine leather | ●Genuine leather |
Sports style seat | - | - | - |
main seat adjustment | ● front and rear adjustment ● Backrest adjustment ● Height adjustment (4-way) ●lumbar support (4-way) | ● front and rear adjustment ● Backrest adjustment ● Height adjustment (4-way) ●lumbar support (4-way) | ● front and rear adjustment ● Backrest adjustment ● Height adjustment (4-way) ●lumbar support (4-way) |
Assistant seat adjustment | ● front and rear adjustment ●Backrest adjustment ● Height adjustment (2-way) | ● front and rear adjustment ●Backrest adjustment ● Height adjustment (2-way) | ● front and rear adjustment ●Backrest adjustment ● Height adjustment (2-way) |
Main/passenger seat electric adjustment | Driver●/Vice Drive● | Driver●/Vice Drive● | Driver●/Vice Drive● |
front seat function | ● heating | ● heating ●Ventilation ● massage | ● heating ●Ventilation ● massage |
Power seat memory function | Driver●/Vice Drive● | Driver●/Vice Drive● | Driver●/Vice Drive● |
Front passenger seat rear adjustable button | - | ● | ● |
Second row seat adjustment | ●Backrest adjustment | ● front and rear adjustment ●Backrest adjustment | ●Backrest adjustment |
The second batch of electric seat adjustment | - | - | ● |
2nd row seats function | - | ● heating ●Ventilation | ● heating ●Ventilation ● massage |
Rear small table board | - | - | - |
Second row independent seats | - | - | - |
Seats lay out | - | ●2-3-2 | - |
rear seats put down form | Proportionally | Proportionally | Proportionally |
Electric folding of rear seats | Front● /Rear ● | Front● /Rear ● | Front● /Rear● |
Heating/cooling cup holder | - | - | - |
rear cup holder | ● | ● | ● |
Multimedia configuration | |||
Central control color screen | ●Touch LCD screen | ●Touch LCD screen | ●Touch LCD screen |
Central control screen size | ●14.6inches | ●14.6inches | ●14.6inches |
GPS | ● | ● | ● |
Navigation traffic information display | ● | ● | ● |
roadside assistance call | ● | ● | ● |
Bluetooth phone | ● | ● | ● |
voice recognition system | ●multimedia system ●navigation ●Telephone ●air conditioner | ●multimedia system ●navigation ●Telephone ●air conditioner ●skylight | ●multimedia system ●navigation ●Telephone ●air conditioner ●skylight |
car internet | ● | ● | ● |
4G/5G OTA WIFI | ●4G | ●4G | ●5G |
OTA upgrade | ● | ● | ● |
WIFI | ● | ● | ● |
Multimedia/charging interface | ●USB ●SD ●Type-c | ●USB ●SD ●Type-c | ●USB ●SD ●Type-c |
Number of USB Type-C ports | ●Front2/ rear 2 | ●Front2/ rear 2 | ●Front2/ rear 2 |
Luggage compartment 12V power interface | - | - | - |
Speaker Brand | ●Infinity | ●Infinity | ●Infinity |
Speaker Qty | ●12 | ●12 | ●12 |
phone APP remote control | ● | ● | ● |
Lighting configuration | |||
low beam light source | ●LED | ●LED | ●LED |
high beam light source | ●LED | ●LED | ●LED |
Lighting Features | - | - | - |
LED daytime running lights | ● | ● | ● |
Auto adaptive high low light | ● | ● | ● |
automatic headlights | ● | ● | ● |
Turning Assist light | ● | ● | ● |
Turning headlight | - | - | - |
Headlight rain and fog mode | - | - | - |
Headlight height adjustable | ● | ● | ● |
headlight cleaning device | - | - | - |
Headlights delay turn off | ● | ● | ● |
touch reading light | ● | ● | ● |
In-car ambient lighting | ●multicolor | ●multicolor | ●multicolor |
Glass/Rearview mirror | |||
Front/rear power windows | Front● /Rear ● | Front● /Rear ● | Front● /Rear ● |
One window lift function | ● All Car | ● All Car | ● All Car |
Window anti-pinch function | ● | ● | ● |
Exterior mirror function | ●Electric adjustment ●Electric folding ●Rearview mirror heating ●lock auto folding car | ●Electric adjustment ●Electric folding ●Rearview mirror memory ●Rearview mirror heating ●Reverse automatic down turn ●lock car automatic folding | ●Electric adjustment ●Electric folding ●Rearview mirror memory ●Rearview mirror heating ●Reverse automatic down turn ●lock car automatic folding |
Inside rearview mirror function | ●Manual anti-glare | ●Automatic anti-glare | ●Manual anti-glare Streaming rearview mirror |
Rear sunshade curtain | - | - | - |
Rear privacy window | ● | ● | ● |
interior vanity mirror | ●Vice driver +light ●copilot+light | ●Vice driver +light ●copilot+light | ●Vice driver +light ●copilot+light |
rear wiper | ● | ● | ● |
Sensor wiper function | rain sensor | rain sensor | rain sensor |
Air conditioner/refrigerator | |||
Air conditioner temperature control method | ●automatic AC | ●automatic AC | ●automatic AC |
Rear independent air conditioner | ● | ● | ● |
rear air outlet | ● | ● | ● |
temperature zone control | ● | ● | ● |
car air purifier | ● | ● | ● |
PM2.5 filter | ● | ● | ● |
negative ion generator | - | - | ● |
Car refrigerator | - | - | - |
