PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Songqi
Model Number :
SQ100
Certification :
internal control
Packaging Details :
Packaging film package and wooden binding
Supply Ability :
10 Set/Sets per Month
Price :
Negotiable
MOQ :
Negotiable
Payment Terms :
D/P, D/A, L/C, T/T
Delivery Time :
15-20
Substrate :
Iron
Coating :
Painting
Voltage :
110V/120V/127V/208V/220V /240V/380V/415V/460V
Power :
4KW
Dimension(L*W*H) :
L2200*W2100*H2250mm
Installation site :
spray booth
Spraying method :
air spray
spray gun :
air spray gun
pump :
diaphragm pump
Port :
Shenzhen
Description

PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying

New condition 5 Axis Spray Painting Machine and automatic spray coating machine for plastic parts

Product Application

As we know, UV paint is more sticky than normal paint, so the paint supply system and spray gun must be better than normal.To get a good coating film, the automatic spraying is a good choice for you. The machine features of five axis reciprocaing machine are as follows.

Machine features:

1. This machine is widely used in many industry. Generally speaking , standard type of this machine has two product tray. If you want to buy a machine with four product tray, then you will get double yield under the premise of high quality coating.

2. It is easy to debug the machine. You can finish debugging for usual product in 15 minutes. The program writing of machine is regard one plane of product as a program segment. When you finish setting the start point , end point and the spraying speed, then you have finished a program segment. After finish every program of plane, then the complete program is finished.

3. This machine has continuous spraying method and step spraying method.

4. The atomization and sector, painting output of spray gun can be controlled by computer. When the machine begin to spray , the spray gun can blow, in order to blow dust.

5. It is easy to use this machine ,and you can store 100 programs of product. The machine operated by fully digital computer.

SPECIFICATIONS FOR MACHINE
Control system
1.Japanese OMRON PLC

2.Taiwan WEINTEK Color industrial touch screen

3.Schneider Electric switch and Power Supply

4.Japanese OMRON relay
Aluminium profile module
Our own mold
Drive system
Japanese Panasonic servo drive system

Transmission system
5. Aluminum profile module

6.Taiwan HIWIN Linear guide rail

7. Taiwan HIWIN Silent slide

8. Precision synchronous wheel

9. Italy MEGADYNE synchronous belt with steel wire
10. Rack and pinion drive

11. positioning accuracy difference ±1㎜
Product exchange platform
11.Precision divider

12.Taiwan CPG Gear motor

13.Japanese Mitsubishi frequency converte
Product rotation platform
14. Precision divider

15. Can be 90 degrees, 180 degrees rotation, continuous rotation
Spray gun
air spray gun : Japanesen DEVILBISS
Paint supply system
18. American GRACO 308 diaphragm pump or Plunger pump

19. Pneumatic agitator produce from Taiwan,China

20. Taiwan AIRTAC Solenoid valve, Pressure regulating valve, Pressure gauge
Programming mode
Off line programming
Power supply
4KW
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
Certifications
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
Detailed Images
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying

spray gun

Japanese DEVILBISS air spray gun

Main Features

Name: diaphragm pump
Brand: GRACO
Original: American

PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
Our Service
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
PLC Control 5 Axis Spray Painting Machine 220V UV Paint Air Spraying
