40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Songqi
Model Number :
SQSB100
Certification :
ISO9001
Packaging Details :
Packaging film package and wooden binding
Supply Ability :
30 Set/Sets per Month
Price :
Negotiable
MOQ :
Negotiable
Payment Terms :
D/P, D/A, L/C, T/T
Delivery Time :
20-35days
Substrate :
Steel
Voltage :
110V/120V/127V/208V/220V /240V/380V/415V/460V
Power :
7KW
Dimension(L*W*H) :
W2400*D2200*H2400mm
lighting :
two explosion light
Size :
W2400*D2200*H2400mm
Exhausting system :
4KW centrifugal fan
Water pump :
3HP high quality vertical water pump and enviromental PVC tube
Style :
Single side water curtain and Up exhaust
Underframe :
40mm stainless steel square
Description

40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine​

Lowest price spray booth stainless steel water washing spray booth for painting machine

Product Application

Water curtain spray cabinet is mainly composed of a spray chamber, a water tank, adjustable feet cup, plate and the top plate (by bolts), positive overflow tank, water curtain plate, scroll plate, diversion plate, water retaining plate, front curtain plate, paint mist purification (water pipe), gas water separation chamber, water tank, water filter circulating system, explosion-proof lighting device, axial fan, water pump and pipe fittings (movable and detachable) and control system components, (zigzag plate, scroll device, gas separation chamber of unique structure, high efficiency of removing paint)

SPECIFICATIONS FOR UV CURING MACHINE
Size
W2400*D2200*H2400mm
Style
Single side water curtain
Frame
Side plate: 1.2mm stainless steel plate

Bottom water tank: 1.5mm stainless steel plate

Water cuitain plate: 1.5mm stainless steel plate

Underframe:40mm stainless steel square
Water pump
3HP high quality vertical water pump

Enviromental PVC tube
Exhausting system
4KW fan
Light
2 lamp explosion-proof lamp
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine

Main Features

1) It make a better working environment to keep workeer's health.

2) Small area, saving space

Certifications
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
Our Service
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
Packaging
Size
2200(L) * 1200(W) * 1400 (H)
Weight
530kg
Packaging Details
The normal package is wooden box. If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
40mm Stainless Steel Curtain Spray Booth 7KW For Painting Machine
Delivery
Ocean Shipping
