Light Keel Cold Roof Truss Purlin Roll Forming Machine CE standard Cr12 Rollers
Light Keel Cold Roof Truss Purlin Roll Forming Machine CE standard Cr12 Rollers
Light Keel Cold Roof Truss Purlin Roll Forming Machine CE standard Cr12 Rollers
Light Keel Cold Roof Truss Purlin Roll Forming Machine CE standard Cr12 Rollers
Light Keel Cold Roof Truss Purlin Roll Forming Machine CE standard Cr12 Rollers
Light Keel Cold Roof Truss Purlin Roll Forming Machine CE standard Cr12 Rollers
Specifications
Brand Name :
ZH
Model Number :
ZH-35
Certification :
CE/SGS/ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
$9000-15000/set
Supply Ability :
80 sets/months
Delivery Time :
30 working days
Packaging Details :
packaged by waterproof film cover
Type :
Cold roll forming machine
Suitable material :
GI
Thickness :
0.5mm / 0.6mm
Power :
7.5kw+4kw
Warranty :
2 years
Speed :
25m/min
Description

Light Keel Cold Roof Truss Purlin Roll Forming Machine

Quick Detail Light Keel Cold Roof Truss Purlin Roll Forming Machine

1. Suitable to process: Color steel plate

2. Width of the plate:175mm

3. Rollers: 12rows

4. Dimensions: 6.1*1.15*1.51m

5. Power: 4.5+3kw

6. Rolling material: shaft bearing steel(quenching)

7. Thickness of the plate:0.3-0.6mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control

Description:

Light Keel Cold Roof Truss Purlin Roll Forming Machine Main parameter

No. Main parameter of Keel Roll Forming Machine
1 Suitable to process Color steel plate
2 Width of the plate 175 mm
3 Rollers 12 rows
4 Dimensions 6100*1150*1510mm
5 Power 4.5+3kw
6 Rolling material shaft bearing steel(quenching)
7 Thickness of the plate 0.3-0.6 mm
8 Productivity 20m/min
9 Diameter of the roller Φ50mm
10 Voltage 380V 50Hz 3phases
11 Material of the cutting plate Cr12
12 Hydraulic 40#
13 Processing precision Within 1.00mm
14 Control system PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-cutting

1).automatic vertical single head uncoiler : 1 set
a.Using hand tightening design, Coil ID:Ф460mm-Ф520mm, coil OD:Ф1400mm, Loading:2000kg
b.Frequency conversion automatic uncoiling
c.Power:2.2KW
2). Frame: Using steel plate welding, the overall annealing to stress treatment, to ensure long-term use without deformation; and CNC machining center processing to ensure dimensional accuracy.
3). Arch: Main arch is box structure, box is CNC machining center processing, auxiliary arch is independent structure.
4). Rolling mould: Cr12mov die steel, after vacuum hardened HRC60-62 ° to refine the hole and the end of the face, CNC lathe finishing the roller surface.
5). Main axis: Material for 40Cr tool steel, quenching and tempering heat treatment, external grinding finishing
6). Drive system: Servo motor and reducer linkage, between the wheel with precision hard tooth gear oil immersion operation, to ensure that the use of long time without wear.
7). Hydraulic system
a. Energy storage structure, energy saving and environmental protection
b. Hydraulic components: Germany Bosch Rexroth products
8). Punching mould
Die model material are used S45C tool steel, mold insert with D2 or SKD11 high-quality steel, mold parts with Japan's rice products.
9). Electrical parts
a.Original imported motion controller and PLC

b.. International first-class brand low voltage components
10). CNC inkjet printer
a.Configuration of industrial-grade high quality solvent-based electronic inkjet printer, print writing clear and solid, easy to install
b.Common solvent based inks,easy to buy, and economical to use
c.Automatically prints automatically generated by the design software, without human intervention
d.By Frame Mac LGS maker production control system can add any additional information, such as, company name,logo, websites and so on.
