Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut
Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut
Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut
Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut
Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut
Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut
Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut
Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut
Specifications
Brand Name :
ZH
Model Number :
ZH-180
Certification :
CE
Place of Origin :
Hebei , China
MOQ :
1 set
Price :
USD15000-32000 per set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 sets per month
Delivery Time :
30 days
Packaging Details :
One set machine needs one 40GP for shipment , PLC system packed with Carton box .
Type :
Notch Punching Steel Door Frame Roll Forming Machine with 45 degree cut
Feature :
Advanced design
Special :
Hydraulic cutting
Power :
7.5+5.5KW
Volgate :
380V or custom
Roller :
No.45 steel with heat treatment
Warranty :
1 year free
Service :
Whole life
Description

Notch Punching Steel Door Frame Roll Forming Machine with 45 degree cut

More information feel free to contact Rebecca

WhatsApp/Wechat : +86 15720370230

Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut

Zhongheng roll forming machinery Co., Ltd is the manufacturer specilized in Roof Steel Tile roll forming machine. We provide an extensive line of products, which includes roof and wall panel machine , roof tile machine, purline forming machine, floor decking machine,gutter forming machine,roller shutter machine etc.

What's your machine application ?
Our roll forming machines can produce various of steel roof and wall panel, it is a new building materials, the products are widely used as the roof and wall of factory, warehouse, garage, gymnasium, exhibition center, cinema, theatre, etc. It has many advantages, such as easy installation, short building period, beauty, light weight but high strength.

Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut

How about the parameters for Notch Punching Steel Door Frame Roll Forming Machine with 45 degree cut ? If need some change, just tell me

Notch Punching Steel Door Frame Roll Forming Machine with 45 degree cut
1 Suitable material Color steel sheet ,galvanized steel sheet, aluminium sheet
2 Width of material 165mm or as you required
3 Thickness of material 1.2mm or as your needs
4 Working speed 10m/min
5 Main motor power 4kw with cycloidal reducer
6 Hydraulic station power 4kw
7 Electrical control system PLC control system
8 Shaft diameter 70mm
9 Roller station

10 rows

10 Material of roller High grade 45# forged steel plated with hard chrome plating
11 Material of cutting Cr12 mould steel with quenched treatment
12 Voltage 380V 3phase 50HZ or as the customer's requirements
13 Dimension 3000x1500x1310mm
14 Weight About 2T
15 Working time Can be 24 hours
16 Workers 1-2 Only

Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree CutNotch Punching Steel Door Frame Roll Forming Machine With 45 Degree CutNotch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut

Please note: All the parameters can be designed as customer's requirements.

Where is your factory located ? How can I visit you ?
Zhong Heng Roll forming machinery is located at Industrial Zone of Botou , Hebei Province of China. Welcome to visit us by:

1. Fly to BEIJING or TIANJIN Airport, then take high speed train from BEIJING NAN to CANGZHOU XI, about 1 hour, I will pick up you there.
2. Fly to SHANGHAI Airport, then take high speed train from SHANGHAI HONGQIAO to CANGZHOUXI, about 4.5 hour,I will pick up you there.

Free to Contact us

Notch Punching Steel Door Frame Roll Forming Machine With 45 Degree Cut Rebecca Yang
Company Cangzhou zhongheng machine manufacture Co.,ltd
Address Nancang road botou city hebei province China
Whatsapp +8615720370230
Youtube https://www.youtube.com/channel/UCFbWECOfV2xeM-WCaww_iPQ
