PPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel Rollers
PPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel Rollers
PPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel Rollers
PPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel Rollers
PPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel Rollers
PPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel Rollers
PPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel Rollers
PPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel Rollers
Specifications
Brand Name :
ZH
Model Number :
ZH-860
Certification :
CE
Place of Origin :
Hebei , China
MOQ :
1 set
Price :
USD8000-15000 per set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 sets per month
Delivery Time :
30 days
Packaging Details :
One set machine needs one 40GP for shipment , PLC system packed with Carton box .
Type :
Roofing Sheet Roll Forming Machine
Feature :
Long life time
Special :
Hydraulic cutting
Power :
5.5+4KW
Volgate :
380V or custom
Roller :
No.45 steel with heat treatment
Warranty :
1 year free
Service :
Whole life
Description

PPGI GI Metal Roofing Sheet Roll Forming Machine use No.45 steel rollers

PPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel Rollers

PPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel RollersPPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel Rollers

Working processing of Metal Roofing Sheet Roll Forming Machine

Uncoiling→Feeding material into machine→Roll forming→Measuring length→ Auto cutting→Products receiving

PPGI GI Metal Roofing Sheet Roll Forming Machine With No.45 Steel Rollers

Quick Details

No. Name specification
1. Main part of machine Decoil, rolling system, cutting system, output tabel
2. Control system PLC automatic control
3. Main motor power 3kw or as customer requirement
4. Hydraulic motor power 4kw or as customer requirement
5. Hydraulic pressure 10-12Mpa
6. Voltage 380V/50HZ (or as customer requirement)
7. Main Frame 300H beams
8. raw material galvanized/galvalume/color steel coil, and aluminum coil
9. Feeding thickness 0.2mm to 1.4mm
10. Feeding width 50mm to 1500mm
11. Produce speed 0m/min to 12m/min
12. roller material 45# steel
13. Cutting material Cr12 quenched
14. Machine length 4.8meter to 13meter
15. Total weight 4.5Tons to 8Tons
16. work flow decoiler - feeding and guilding - roll forming - cut as length - out put sheet
17. warrant time 14months
18. Package Standard export package
21. Delivery time from 10-15work days (it is be decided by the order quantity)

1. Can you make the machine according to my design or photo type?

A: Yes. We have an experienced team to work out the most suitable design and production plan

for the machine.

2: How can we be assured that you will deliver us quality machine with spare parts?

A:1. Customers to send the technical people to our factory for checking the quality.

2.We can send the technicians to the buyer`s factory for the installation of the machine.

3.What policy of your garentee?

A: Within the One-YEARS period, we could supply you the replacement parts free of charge

for any damaged parts caused by quality problems after two years,you need to buy by factory cost.

Free quotation please contact Rebecca

WhatsApp/Wechat: +86 15720370230
