ACES Viper II Fluke Vibration Meter Tester Machine For Analysis Rotor Tracking And Balancing
ACES Viper II Fluke Vibration Meter Tester Machine For Analysis Rotor Tracking And Balancing
ACES Viper II Fluke Vibration Meter Tester Machine For Analysis Rotor Tracking And Balancing
ACES Viper II Fluke Vibration Meter Tester Machine For Analysis Rotor Tracking And Balancing
ACES Viper II Fluke Vibration Meter Tester Machine For Analysis Rotor Tracking And Balancing
ACES Viper II Fluke Vibration Meter Tester Machine For Analysis Rotor Tracking And Balancing
ACES Viper II Fluke Vibration Meter Tester Machine For Analysis Rotor Tracking And Balancing
ACES Viper II Fluke Vibration Meter Tester Machine For Analysis Rotor Tracking And Balancing
Specifications
Brand Name :
ACES Systems
Model Number :
ACES Viper II
Place of Origin :
USA
MOQ :
1EA
Price :
Please consult customer service
Payment Terms :
T/T
Supply Ability :
Please consult customer service
Delivery Time :
5-8 work days
Packaging Details :
1*1*1
Dimensions :
10.5 inches wide, 9.75 inches long, 5 inches deep
Charging Time :
3.0 Hours (approximately)
Condition :
Factory New
Use :
Aircraft Weight and Center of Gravity Measuring
Description

Vibration Tester (ACES Viper II),It combines vibration analysis, rotor tracking and balancing, fan adjustment balancing, propeller balancing, and progressive analysis required for high-end engines

The VIPER II is a versatile and compact instrument that combines the vibration analysis, rotor tracking and balancing, fan adjustment balancing, propeller balancing, and progressive analysis required for high-end engines. With the VIPER II, you can easily perform all maintenance tasks on almost any airframe or engine.

ACES Viper II Fluke Vibration Meter Tester Machine For Analysis Rotor Tracking And Balancing

Vibration refers to the displacement or oscillation of an object away from its original position. In the use of aircraft, harmful vibration beyond the standard will lead to rapid wear of components, structural damage, and power plant failure. Therefore, the aircraft department accessories manufacturers require or suggest that the engine and the main rotating parts do regular vibration testing and balance inspection, early detection of fault symptoms to take measures, so as to reduce maintenance costs and accident risks.

New features of VIPER II

The ability to simplify, store, and process large amounts of data is essential for field maintenance personnel

Since the data is obtained from a similar engine environment, the balance results can be directly related to the vibration test

With ACES 'artificial intelligence, the weight scheme is constantly adjusted as the engine changes

Saves up to 67% of data acquisition time compared to complex multi-point balanced test runs.

performance parameter

1, memory capacity: 32M
2, LCD screen: 320X240 pixels
3, phase accuracy: 1 degree
4, amplitude accuracy: ±1%
5, maximum amplitude: 20IPS
6, balance speed: 60RPm-60000rpm
7, maximum spectral analysis: 1800000RPM (30KHz)
8, sensitivity: 20mv/ips
9, minimum signal: -80db

VIPER II-2 analyzer channels for vibration analysis and balancing
Vibration input 9.5 Volt Peak - Peak, 0 to 240 phase values for each IPS sensor of 20 millivolts
Sensor Type A universal sensor that accepts any form of vibration signal input (acceleration, rate, phase) and any voltage. The charging device requires an external charge amplifier.
Vibration amplitude Accuracy The frequency range goes up or down 1%
Frequency Range Maximum 30,000 Hz (1.8 million RPM)
Speed input 60 to 10,000 RPM more accurate than 1 degree phase
Display All-day readable color with ultra-bright LED backlight
power supply LCD display can last up to 7 days rechargeable lithium-ion battery
size 10.5 inches wide, 9,75 inches long, and 5 inches high
weight About 6 pounds (2.8 kg)
