928 wheel loader is a versatile machine,consisting of a 1.0m³bucket which is supported by a boom structure and is used to dig,fill,scoop,lift,carry and dump materials into trucks,piles,bins and so on. The 928 front-end wheel loader is 4-wheel drive and all the axles and pumps are domestic which are produced by the first-class factories in China.The engine is Yunnei with 76KW rated power and it has an articulated body i.e.a hinge between the front and the rear assembly.It is fully hydraulic control which makes the whole machine more easily to operate and the operator can be able to control the boom and the bucket quickly and easily.The whole wheel loader is made of manganese steel.
| Performance | Loader lifting capacity | 2000KG |
| Operating weight | 5960KG | |
| Rated bucket capacity | 1m³ | |
| Max. tractive force | 58KN | |
| Max. breakout force | 55KN | |
| Max. grade ability | 30° | |
| Max. dump height | 2500mm | |
| Max. dump reach | 900mm | |
| Overall dimension(L×W×H) | 5700×2140×2960mm | |
| Min. turning radius | 4750mm | |
| Engine | Model | Yunnei |
| Type | Inline, water-cooled, four stroke | |
| Cylinder-Inner diameter×stroke | 4-108×115mm | |
| Rated power | 76KW | |
| Maximum torque | 236N.m | |
| Min fuel-consumption ratio | ≤213g/kw.h | |
Transmission system | Torque converter | YJ280FX |
| Gearbox mode | Countershaft power shift | |
| Gear shift | 2 forward shift and 2 reverse gears | |
| Maximum speed | 26.5km/h | |
| Drive axles | Wheel base | 2260mm |
| Wheel tread | 1680mm | |
| Ground clearance | 306mm | |
| Hydraulic system | System working pressure | 16Mpa |
| Boom lifting time | 4.8±0.2s | |
| Total time | 9.2±0.5s | |
| Fuel tank capacity | 90L | |
| Self-levelling bucket | yes | |
| Brake system | Service brake | Air assist disc brake on 4 wheels |
| Parking brake | Manual brake | |
| Tire | Tire specification | 16/70-20 |
| Front tire pressure | 0.345Mpa | |
| Rear tire pressure | 0.28Mpa |
