1500W Power Station Emergency Power Supply Pure Sinewave Solar Charge multi protection
YJ Series Portable Solar Power Generator
Portable Solar Power Generator For Outdoor RV/Van Camping 600W Li-Battery Multi Outlets
Key Features
♦ It is pure sine wave AC output, will not damage devices.
♦ High quality and capacity Li-batteries
♦ No engine, so, it is no fuel, no fumes, no pollution
♦ More than 1000 times charging and discharging cycle*
♦ Support the solar panels charge
♦ Low noise, almost 50dB in 1meter.
♦ Real-time display parameters such as voltage, current, power, battery, and working mode
♦ Automatic computing power equipment, accurately show the rest of the time
♦ Overcharge, discharge, overload, overheating and short circuit protection function
♦ LifePo4 type up to 2000 cycles
YJ series supports charging for all your necessities and electronic devices, GoPros, drones, lights, or speakers. It’s engineered without an engine for clean power without the hassle of fumes, fuel, or noise to make it an ultra-versatile silent power source that is maintenance-free. With solar panel capability, this station is designed for outdoor activities like camping, tailgating, or festivals where you need power on the go. Functional for indoor use as well, it conveniently comes with a reading light and a dual mode flashlight for low light environments.
Wide Application
Specifications
Model | YJ300 | YJ600 | YJ600+ | YJ1000 | YJ1000+ |
Rated power | 300W | 600w | 600w | 1000w | 1000w |
AC Input voltage | (165-275)VAC | ||||
AC Input Frequency | 50Hz ±5% | ||||
AC Output voltage | AC220V/230V±5%(BATTERY MODE) | ||||
AC Output Frequency | 50/60HZ±0.2%(BATTERY MODE) | ||||
Output waveform | Pure sine wave | ||||
Efficiency | >85% | ||||
Transfer time | 4-6ms | ||||
Battery capacity | 12V38ah Lead-acid | 12v38ah Lead-acid | 12V40AH LiFePo4 | 12v65ah Lead-acid | 12V65AH LiFePo4 |
AC Charge time | 4H | 6H | 5H | 6H | 6H |
Max AC Charge current | 0-40A(Optional) | ||||
Solar input voltage | PWM (12V TO 25V, 24V TO 50V, 48V TO 80V) | ||||
Solar charge current | 40A | ||||
Solar panel | 100W | 150w | 100W*2 | 150W*2 | 150W*2 |
Solar panel price | |||||
Solar charge time | 5h | 6h | 5H | 6H | 5H |
Distortion rate | <3% (full load)Linear load | ||||
<6% (full load)Non-Linear load | |||||
Protection | Over voltage, over term, over load, short circuit, battery voltage high & low, AC input voltage high & low, automatic re-cover | ||||
Load peak ratio | 3:1 (Max) | ||||
Overload capacity | 110-130%,turn off after 10 secs, over 130% maintain 0.3 secs and then shut down | ||||
Operation term | -25~45°C | ||||
Humidity | 5%~90%( non-condensation) | ||||
Altitude | ≤ 4500m | ||||
Cooling | Air cooling(inner term over 45°C) when machine temperature is up to 45℃, fan works; when it’s lower than 45℃, fan stop automatically. | ||||
MTBF | ≥50000H | ||||
Dimension | L430*W195*H360mm | L430*W195*H360mm | L430*W195*H360mm | L430*W195*H360mm | L430*W195*H360mm |
Package dimension | L470*W280*H420mm | L470*W280*H420mm | L470*W280*H420mm | L470*W280*H420mm | L470*W280*H420mm |
Net weight | 17kg | 25kg | 10kg | 26kg | 12kg |
Gross weight | 19kg | 28kg | 12kg | 29kg | 14kg |
