Small Computer Backup Power Supply HT11 1K Online High Frequency 1KVA 800W
Small Computer Backup Power Supply HT11 1K Online High Frequency 1KVA 800W
Small Computer Backup Power Supply HT11 1K Online High Frequency 1KVA 800W
Small Computer Backup Power Supply HT11 1K Online High Frequency 1KVA 800W
Specifications
Brand Name :
J-ENERGIZE
Model Number :
JET-HT11 1K (R)
Place of Origin :
XIAN, CHINA
MOQ :
1 Unit
Payment Terms :
L/C, T/T, Negotiable
Delivery Time :
Negotiable
Packaging Details :
Carton
Installation type :
Tower
Nominal capacity :
1KVA / 800W
Battery pack :
24V built-in battery
Max. Battery Input Inrush Current :
< Around 150% of Nominal Current
Battery backup time :
Half Load ≥ 10mins, Full Load ≥ 5mins (Standard)
Application :
Telecommunications,Networking,Computer
Protection :
Overvoltage,Unbalanced Loads,Short Circuit,Overcurrent,overload/overshort/discharge/charge/short circuit
Wave form :
Pure Sine wave
Product name :
Uninterrupted Power Supply
Power factor :
0.8
Weight :
8.5 kgs
Transfer time :
0 ms
Description

HT11 1K Online High-Frequency Uninterruptible Power Supply 1KVA 800W Computer Small UPS

JET-HT11 1K (R) Online High-Frequency UPS

Model HT11 1K (R) Online High-Frequency Uninterruptible Power Supply, is 1KVA 800W tower type UPS, no break, built-in battery.

Application

Small data center

Server room

Internetwork laboratory

Communication devices

Office terminals

Workstation

Key Features

  • It is high-frequency online dual conversion.
  • DSP (digital signal processors) ensures the better quality and high performance.
  • It is pure sinewave, stable and reliable, no matter in utility mode or battery mode, it is sinewave power output with low distortion.
  • Microprocessor control ensures high reliability
  • Input power factor correction (PFC), input power factor up to 0.98
  • AC Output power factor is 0.8
  • Wide input voltage range and frequency range fit to harsh power grid condition.
  • It can fit to generator.
  • Zero delay time ensures the safety and reliability of load. when the grid power is cut off or recovers, there is absolutely no transfer time.
  • 2U rack mount Installation.

Specifications

Model

Specifications

1K (R)
Nominal Capacity 1000VA/800W
AC Input Voltage Range 115~300VAC±5V
Frequency Range 45~55Hz ±0.5Hz
Bypass Voltage 80VAC × (1±5%) ~ 285VAC × (1±5%)
Battery Input Battery Pack 24V
Built-in or Outside Built-in
Backup Time Half Load ≥ 10mins, Full Load ≥ 5mins (Standard)
Max. Battery Input Inrush Current < Around 150% of Nominal Current
Battery Charging Time 5Hours up to 90%(standard); Depends on the Battery Qty (long-term)
AC Output Voltage 220VAC ±1% (Invert Output)
Frequency 50±5Hz (Normal AC Output) 50Hz±1% (Abnormal AC Output)
Waveform Pure Sinewave
THD THD <3% (Linear Load), THD <8% (Non-Linear Load)
Power Factor 0.8
Overload 130% of Continuous Load More Than 30sec, Recovery as 90% of Load
Current Peak Factor 3:1
Grid/Batteries Conversion Time 0 ms
Tower Type Communication and Monitoring Functions RS232 (Can Change as RS 485), Stem Node
Weight (kgs) 8.5
Dimension (W x D x H) (mm) 355×145×225
Rack Type Weight (kgs) 10.8
Dimension (W x D x H) (mm) 460×440×90
Installation Rack and wall mounting
