4 Bag Filter Housing 1-24 Multi Rocker Ring Type Liquid Filter Bag Housings
4 Bag Filter Housing 1-24 Multi Rocker Ring Type Liquid Filter Bag Housings
4 Bag Filter Housing 1-24 Multi Rocker Ring Type Liquid Filter Bag Housings
4 Bag Filter Housing 1-24 Multi Rocker Ring Type Liquid Filter Bag Housings
Specifications
Brand Name :
YATE
Model Number :
Multi bag filter
Certification :
ISO9001,CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
20 Set/Sets per Day multi bag filter housing
Delivery Time :
To be negotiated
Packaging Details :
multi bag filter housing Packaging: Wooden case
Video outgoing-inspection :
Provided
Function :
liquid filter
Inlet and our let size :
1/2 or 3/4 inches or customized
Working Pressure :
12 bar
Filter Bag Material :
PP/PE/PTFE/SS
Min. Filtration Precision :
0.5-500 μm
Name :
1-24 bag filter
Application :
Water Treatment
Description

Bag filter can be customized, the maximum number of bags in the

filter can reach 200 bags, suitable for fine chemical industry, water

treatment system, paper making, automobile industry, petrochemical

industry, mechanical processing, coating, electronics, etc.

4 Bag Filter Housing 1-24 Multi Rocker Ring Type Liquid Filter Bag Housings

Model
Filter Bag#
Filter Bag
Qty
Filtration Area(m2)
Connection
Max.Flow
(m3/h)
Working Pressure(MPa)
YT-1D
1#
1
0.25
DN50
20
0.6
YT-2D
2#
1
0.5
DN50
40
0.6
YT-2P2S
2#
2
1
DN50-DN100
70
0.6
YT-3P2S
2#
3
1.5
DN80-DN100
100
0.6
YT-4P2S
2#
4
2
DN80-DN100
140
0.6
YT-5P2S
2#
5
2.5
DN80-DN100
175
0.6
YT-6P2S
2#
6
3
DN80-DN100
240
0.6
YT-7P2S
2#
7
3.5
DN80-DN100
245
0.6
YT-8P2S
2#
8
4
DN100-DN200
280
0.6
YT-10P2S
2#
10
5
DN150-DN200
350
0.6
YT-12P2S
2#
12
6
DN150-DN250
420
0.6
YT-14P2S
2#
14
7
DN200-DN250
490
0.6
YT-16P2S
2#
16
8
DN200-DN300
560
0.6
YT-18P2S
2#
18
9
DN250-DN350
630
0.6
YT-20P2S
2#
20
10
DN250-DN400
700
0.6
YT-22P2S
2#
22
11
DN300-DN450
770
0.6
YT-24P2S
2#
24
12
DN350-DN450
840
0.6

PROFESSIONAL CUSTOMIZATION BY TECHNICAL TEAM
Multi-bag filter is designed for high capacity pollution or large flow filtration requirements, provide
2-24 bags of design customization, import and export of a variety of sizes optional (DN80-DN250),
convenient direct connection, ensure sufficient equipment strength and pipeline load bearing
capacity, quick open design, unscrew the nut to remove the cover, convenient maintenance, Made
of high-quality stainless steel 304, 316L and other material.
4 Bag Filter Housing 1-24 Multi Rocker Ring Type Liquid Filter Bag Housings
Bag filter housing Internal structure
1.Each bag has a separate locking device
with no side leakage opportunities.
2.Integrated design of precision without
distortion.
3.Integrated precision with lifting device.
4.O-ring seal, high-strength and quick bolts.
4 Bag Filter Housing 1-24 Multi Rocker Ring Type Liquid Filter Bag Housings
Bag filter is a widely used for liquid filtration,it can remove the particles of different size from liquid,
in order to achieve liquid filtration,purification,separation,recovery purposes.It consists of three parts:
bag housing,supporting basket and filter bags.According to flow rate,you may use multiple bags in a
bag housing.First,the liquid enter into the housing from the inlet,which may placed in the side or on
the top,and then flow into the filter bag which is braced by basket.Due to the impact pressure of fluid,
the bag will extend and the liquid get evenly filtered through the bag and flow out of the outletpipe.
Impurities are trapped in the bag,the filtration process is complete.When you replace or clean the bag,
just simply loosen the bolt,rotary hand wheel lifting the lid,and get the bag.
4 Bag Filter Housing 1-24 Multi Rocker Ring Type Liquid Filter Bag Housings
4 Bag Filter Housing 1-24 Multi Rocker Ring Type Liquid Filter Bag Housings
