Stainless Steel Cartridge Filter Housing Water Treatment Sanitary Filter Housing
Stainless Steel Cartridge Filter Housing Water Treatment Sanitary Filter Housing
Stainless Steel Cartridge Filter Housing Water Treatment Sanitary Filter Housing
Stainless Steel Cartridge Filter Housing Water Treatment Sanitary Filter Housing
Stainless Steel Cartridge Filter Housing Water Treatment Sanitary Filter Housing
Stainless Steel Cartridge Filter Housing Water Treatment Sanitary Filter Housing
Specifications
Brand Name :
YATE
Model Number :
Cartridge Filter Housing
Certification :
ISO9001,CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
20 Set/Sets per Day
Delivery Time :
7 days
Packaging Details :
wooden case
Working Pressure :
0.2 μm
Usage :
Liquild Filter
Filter Material :
PP/PE
Material :
Stainless Steel 304
Size :
Customized Size
Type :
Single bag / multiple bags
Video outgoing-inspection :
Provided
Description

Microporous filters can filter liquids and gases, with advantages such as high filtration accuracy, fast filtration speed, less adsorption, no media detachment, acid and alkali corrosion resistance, and easy operation. There are four types of lengths: 10 '' 20 '' 30 '' 40 '', and there are two types of interface modes: plug-in (222/226 interface) and flat mouth. Introduce advanced technology and manufacture according to FDA standards, with low blockage rate, fast filtration speed, pollution-free, good thermal stability and chemical stability.

Stainless Steel Cartridge Filter Housing Water Treatment Sanitary Filter Housing

Model
Filter element
Filter element Qty
Connection
Max. Flow (m³/h)
Working pressure(MPa)
YT-10*1
10”
1
DN20
0.5
0.5-1.6
YT-20*3
20”
3
DN25
3
0.5-1.6
YT-20*10
20”
10
DN50
10
0.5-1.6
YT-20*7
20”
7
DN40
7
0.5-1.6
YT-30*5
30”
5
DN25
7.5
0.5-1.6
YT-30*11
30”
11
DN40
16.5
0.5-1.6

Our factory can customize many different types of filters for you. You can tell me your requirements, such as the liquid you need to filter, the filtration accuracy, flow rate and other information you need. You can find me anytime and anywhere

Stainless Steel Cartridge Filter Housing Water Treatment Sanitary Filter Housing

Note:

Before opening the filter, please exhaust and release the pressure.

Advantages of stainless steel cartridge filter (beer,wine filtration):

Food grade stainless steel liquid filter housing pp filter core oil filter housing.
can be applied for most particles so it is broadly for precision filter and sterilization.
◆the filter cylinder is 1core,3core,5core,7core,9core,11core,13core,15core
◆the length of folding filter core is 10”,20”,30”,40”
◆the material of the filter core is PP,PTFE,nylon,SS304
◆the diameter of the filter hole is 0.1μm,0.22μm,0.45μm,1μm,3μm,5μm,10μm,30μm,60μm,
and it is selective as hydrophilic (suitable for gas) and hydrophilic (suitable for liquid) according to your requirement.Food grade stainless steel liquid filter housing pp filter core oil filter housing.

Stainless Steel Cartridge Filter Housing Water Treatment Sanitary Filter Housing
