Ounuo Recycled Automatic Non Woven Bag Making Machine With Auto Punching Device
Ounuo Recycled Automatic Non Woven Bag Making Machine With Auto Punching Device
Ounuo Recycled Automatic Non Woven Bag Making Machine With Auto Punching Device
Ounuo Recycled Automatic Non Woven Bag Making Machine With Auto Punching Device
Specifications
Brand Name :
OUNUO
Model Number :
ONL-XA700
Certification :
CE
Place of Origin :
Zhejiang
MOQ :
1 SET
Payment Terms :
T/T,L/C at sight
Supply Ability :
40 set/month
Delivery Time :
30 days
Packaging Details :
Shrink film and wooden case packing
Total power :
28KW
Production Speed :
40-100PCS/Min
Power supply :
220V
Standard :
CE, ISO9000
Computerized :
Yes
Brand :
Ounuo
Color :
Gray and white
Payment :
TT / LC
Description

Ounuo Recycled Automatic Non Woven Bag Making Machine With Auto Punching Device

Bag Making Procedure:


Raw material----bag mouth-----rope feeding-----thermal bonding----side fold----bottom sealing----thermal bonding-----bag cut----collection

Product Description:

Machine suitable for PP non woven fabric, regeneration non woven fabric,lamination non woven fabric etc

The material thiness range is: 30-100GSM

Machine can make non woven fabric shopping bag, handle bag,t-shirt bag,colth bag,file bag,flat bag,box bag,vest bag etc. It can meet the demand of market.

The non woven fabric is an reproducible,environmental materials, it have large market in future.

Specification:

Model ONL-XA700
Non woven bag Type Flat Bag T-shirt Bag Box Bag
Non wove bag width (mm) 100-700mm 300-600mm 300-600mm
Non woven bag length (mm) 300-750mm 200-480mm 300-650mm
Non woven bag gueest (mm) 40-90mm 40-120mm 40-80mm
Bag making speed (pcs/min) 20-90pcs/min 20-90pcs/min 20-90pcs/min
Materials Thiness (g/m2) 35-90GSM 35-90GSM 35-90GSM
Rewinding material diameter 1000mm
Rewinding material width 1600mm
Machine Weight 4000kg
Power Supply 380V,50HZ,ThreePhase
Total Power 16kw
Machine Size 9200x2100x2000mm(I Model)
Sealing part 10Set Top quality ultrasonic

1. Ultrasonic device to seal bags in good quality
2. Computer control, automatic feeding, automatic counting, automatic stopping.
3. Easy to operate and strong sealing effective

4. Photocell to track the color

5. Equipped with servo motor
6. Equipped auto pneumatic punching device

7.Equipped with tension control device.

8. Machine has got CE Certification, SGS Certification, company has obation ISO9001:2008 certification

Sample picture as following:

Ounuo Recycled Automatic Non Woven Bag Making Machine With Auto Punching Device

Ounuo Recycled Automatic Non Woven Bag Making Machine With Auto Punching Device

Company Information

Our company has an area of 8,000 square meters and 130 on-the-job employees. We have four production lines in total. They are divided into non-woven bag making machine lines, soft handle sealing machine lines, flexo printing machine lines and paper cup machine lines. We can ensure our delivery time within 15 working days.

Our strong and professional sales team will provide you with details of machine introduction. According to each customer's different requests, we provide individual and special machine solutions.
