Milk Powder Rotary Packing Machine 10g To 2.5kg For Stand Up Zipper Pouch
Milk Powder Rotary Packing Machine 10g To 2.5kg For Stand Up Zipper Pouch
Milk Powder Rotary Packing Machine 10g To 2.5kg For Stand Up Zipper Pouch
Milk Powder Rotary Packing Machine 10g To 2.5kg For Stand Up Zipper Pouch
Specifications
Brand Name :
Hefei Leadall
Model Number :
LA-GD200
Certification :
CE ISO
Place of Origin :
Hefei , China
MOQ :
1 Set
Price :
USD 25,000.00 to 40,000.00/Set
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
20 Sets Per Month
Delivery Time :
40 to 60 work days
Packaging Details :
Standard Wooden Cases for Export
Filling Weight Range :
10G to 2.5KG
Pouch Size :
(80-200)*(100-300)mm
Capacity :
Up to 50 Bags/Min
Power Supply :
220V/380V, 50Hz
Power Consumption :
2KW
Compressed Air :
0.4 M3/min
Packaging material :
Plastic,Paper
Warranty :
1 Year
Applicable industries :
Food & Beverage Factory
Machine type :
Rotary Pre-made Pouch Packing Machine
Description

10G to 2.5KG Milk Powder Rotary Packing Machine For Stand-up Zipper Pouch

Including:


Bagging Machine + Auger Weigher + Auger Feeder.

Application:

It suits for packing various fine powders, like spice, milk powder, chili powder, herb powder, detergent powder, flour, coffee powder, medicine powder, cosmetic powder, chemical powder, ginger powder, tapioca powder, turmeric powder, starch etc.

Working Flow:

Support bag width up to 200 mm to work with automatic taking bag, coding batch code, opening bag, material filling, bag sealing and output; Option as Doypack, zip bag opener, multi-filling, vibrate bag.

Typical 8 Working-Position:

1)Bag feeding 2)Coding 3) Zip Bag opening 4)Bag opening 5) Filling and Consolidating 6) Option: 2nd Filling.. 7) Air Squeezer 8) Heat-sealing and bag output.

Machine function:

Main Electrical Components:
* SIEMENS PLC
* SIEMENS HMI
* MITSUBISHI SERVO MOTOR
* OMRON
* SCHNEIDER

Main Pneumatic Components:
* SMC Solenoids & Cylinders

Guarding:
* Glass Door Alarm
* Air Pressure Abnormal
* Automatic detection

Functions:

* Tool-less changeover (pre-close zipper)
* Horizontal infeed belt
* PLC adjust bag rel clamping
* Included Vacuum Pump
* Internal grooved cam design
* Newest zipper open device
* Two sealing stations
* Nitrogen gas flush
* Pouch shaker
* Pouch outfeed conveyor
* Stainless Steel shell: SS304
* Date coding
* Air: 0.6m3/min

Main Technical Parameter:

Model LA6-200 LA6-300 LA8-200 LA8-300
Measuring range 5-1500g 100-2500g 5-1500g 100-2500g
Measurement accuracy ±0.5-5g
Bag Type premade bag
Operation Mode Intermittent
Working position six-working position eight-working position
Pouch material Laminated film, PP, PE etc.
Speed Up to 15bags/min Up to 40bags/min Up to 45bags/min Up to 40bags/min
Bag Length 100-300mm 200-500mm 100-300mm 200-500mm
Bag Width 100-200mm 180-300mm 100-200mm 180-300mm
Film Thickness 0.04-0.12mm
Voltage AC 220V/ 50HZ 1phase or per customer needs
Power Consumption 5.5KW 6KW 5.5KW 6KW
Compressed Air Requirement 0.6MPa, 0.36 M3 / Min
Weight 800KG 850KG 900KG 1100KG

Machine photos:

Milk Powder Rotary Packing Machine 10g To 2.5kg For Stand Up Zipper Pouch

Milk Powder Rotary Packing Machine 10g To 2.5kg For Stand Up Zipper Pouch

Optional Items:

Milk Powder Rotary Packing Machine 10g To 2.5kg For Stand Up Zipper Pouch
