Customized Flake Novolac Phenolic Resin P2324 Flame Resistance For Impregnating Glass
Customized Flake Novolac Phenolic Resin P2324 Flame Resistance For Impregnating Glass
Specifications
Brand Name :
HONINGLITE
Model Number :
P2324
Place of Origin :
CHINA
MOQ :
1000KGS
Price :
Negotiation
Payment Terms :
T/T, L/C, D/P
Supply Ability :
5000TONS PRT MONTH
Packaging Details :
25KGS BAG
Appearance :
White Fake
Package :
25kg bag
Melting point :
98-105℃
Gel time :
80-100 s @150℃
Flow :
50-70 mm @ 125℃
Description

Flake Phenolic Novolac Resin P2324 for Impregnating Glass Cloth in Cutting Wheels

Product description

In cutting wheels and depressed center wheels, glass cloth is used to reinforce the wheel. These are referred to as reinforced grinding wheels. The glass cloth used for reinforcing the wheel is impregnated with phenolic resin.

The procedure for coating this glass cloth is as follows:
The glass cloth is dipped in liquid phenolic resin, dried at 80–100 C for 3–10 min, and after drying, is cut to the size of the wheel. The amount of the wet impregnated resin on the glass cloth is controlled from 30 to 50%.

The phenolic resin for this impregnation is mainly a resin consisting of a resole mixed with a novolac. Phenolic resin is designed such that the glass cloth is not tacky when stored and the adhesion is increased between phenolic resin and the grain.
The strength of glass cloth determines rotational strength. Therefore, the fabric strength and the type of weave are important. This effect demonstrates the safe rotational speed of a glass reinforced wheel of 4,500 m/min verses 3,000 m/min for a wheel without glass cloth reinforcement

Flake Phenolic Resin P2324 for Impregnating Glass Cloth are are produced by reacting formaldehyde with phenol under acid conditions with low free phenol and narrow MWD(Molecular weight distribution ).It is novolac resin and crash into flakes.

Specification:

Properties Value Test standard
Curing time @150°C 90-110s GB/T24411-2009
Flow Distance@125°C 35-45mm GB/T24411-2009
Free-phenol 0.5-1.5% GB/T30773-2014
hexa content 8-10% ZJHM-QESP-01-2015
Water content 0.5-2.0% GB/T2683-2008
Screening 200mesh/0.074mm 99% GB/T24411-2009

Packing&Storage


the package is paper-plastics bag in 25KGS each one
The storage life of this product is several months in a cool and dry place in original closed bags
