3801-B-TVH Double Row Angular Contact Ball Bearing 12 X 21 X 7 mm
3801-B-TVH Double Row Angular Contact Ball Bearing 12 X 21 X 7 mm
3801-B-TVH Double Row Angular Contact Ball Bearing 12 X 21 X 7 mm
3801-B-TVH Double Row Angular Contact Ball Bearing 12 X 21 X 7 mm
Specifications
Brand Name :
Optional
Model Number :
3801-B 3801-B-TVH
Certification :
ISO9001
Place of Origin :
Optional
MOQ :
1.pcs
Payment Terms :
T/T, Western Union,Paypal,
Delivery Time :
2 ~ 5 working days
Packaging Details :
Standard Carton Box / Wooden Pallet Case
Size :
12x21x7mm
Stock Quantity :
550.pcs
Type :
Double Row Angular Contact
Precision :
P6, P5 ,P4 ,P2
Contact Angle :
α = 25°
Open Temperature :
–30 °C ~ +150 °C
Description

3801-B-TVH Double Row Angular Contact Ball Bearing 12 X 21 X 7 mm

BearingModel 3801-B 3801-B-TVH
Contact Angle 25°
Type Double Row Angular Contact Ball Bearing
d (mm) 12
D (mm) 21
B (mm) 7
Mass (KG) 0.008
Precision

P6, P5 ,P4 ,P2

We currently have 550.pcs of 3801-B-TVH Double Row Angular Contact Ball Bearing In Stock.If you are in need of 3801-B-TVH Ball Bearing ,just feel free to contact us.We can assure you the best quality; the most competitive prices; the shortest delivery time and the highest quality service.

For more details of 3801-B-TVH ,please feel free to contact me by WhatsApp or SKYPE or E-mail.

Besides,we also have Various Kinds of other Bearings & Guide Blocks In Stock,just click the "

Contact Now "button for Price & other Information.

Bearing

Model

d

(mm)

D

(mm)

B

(mm)
3800-B-TVH 10 19 7
3801-B-TVH 12 21 7
3802-B-TVH 15 24 7
3803-B-TVH 17 26 7
3804-B-TVH 20 32 10
3805-B-TVH 25 37 10
3806-B-TVH 30 42 10
3807-B-TVH 35 47 10
3808-B-TVH 40 52 10
3809-B-TVH 45 58 10
3810-B-TVH 50 65 12
3811-B-TVH 55 72 13
3812-B-TVH 60 78 14
3814-B-TVH 70 90 15
3816-B-TVH 80 100 15

Suffix Description
B Modified internal construction,contact angle α = 25°, without filling slot
C2 Axial internal clearance C2
C3 Axial internal clearance C3
DA Inner ring split
M Solid brass cage, ball-guided
MA Solid brass cage,guidance on outer ring
TVH Solid polyamide snap cage,ball-guided
2RSR Lip seals on both sides
2Z Gap seals on both sides

Introduction

Double row angular contact ball bearings are units with solid inner and outer rings and ball and cage assemblies with polyamide, sheet steel or brass cages. Their construction is similar to a pair of single row angular contact ball bearings in an O arrangement but they are narrower to a certain extent. They differ in the size of the contact angle and the design of the bearing rings.

Sealing

Series 38..-B, 30..-B, 32..-B and 33..-B with the suffix 2RSR are sealed by lip seals on both sides. Contact seals are suitable for giving protection against dust, contamination and damp atmospheres.
Series with the suffix 2Z have gap seals on both sides.


Lubrication

Sealed bearings are greased with a high quality grease and are lubricated for life.

Operating temperature

Open bearings are suitable for operating temperatures from –30 °C to +150 °C.

3801-B-TVH Double Row Angular Contact Ball Bearing 12 X 21 X 7 mm 3801-B-TVH Double Row Angular Contact Ball Bearing 12 X 21 X 7 mm

3801-B-TVH Double Row Angular Contact Ball Bearing 12 X 21 X 7 mm

3801-B-TVH Double Row Angular Contact Ball Bearing 12 X 21 X 7 mm
