Specifications
Brand Name :
SKF
Model Number :
51310
Certification :
ISO9001
Place of Origin :
sweeden
MOQ :
1.pcs
Payment Terms :
T/T, Western Union,Paypal,
Delivery Time :
2 ~ 5 working days
Packaging Details :
Standard Carton Box / Wooden Pallet Case
Stock Quantity :
1200.pcs
Structure: :
Thrust
Type: :
Ball
Direction: :
Single-direction
Cage: :
Sheet metal
Description

Orgional Car Clutch Thrust Industrial Ball Bearings 51212 Fast Delivery

Discription of Thrust Ball Bearing

Thrust ball bearings are produced as single direction or double direction thrust ball bearings. They are designed to accommodate axial loads only and must not be subjected to any radial load.

Thrust ball bearings are separable, i.e. the shaft washer, housing washer(s), ball and cage assembly(s) can be mounted separately. Shaft washers have a ground bore to enable an interference fit. The bore of the housing washer is turned and always larger than the shaft washer bore.

Features of Thrust ball bearings

  • Available in two designs: single direction and double direction.
  • Designs are available with spherical aligning seats or aligning seat washers.
  • High quality steel-ultra clean steel to extend bearing life by up to 80%.
  • High Grade Balls - Quiet and smooth operation even at high speed.
  • Optional seating rings take initial misalignment.

Product Description

Thrust ball bearing 51212 SKF

Technical Specifications:

Basic load ratings
dynamic Ca 62,4 kN
static C0 150 kN
Designation
51212
Fatigue load limit
Pu 5,6 kN
Mass
0,65 kg
Minimum load factor
A 0,12
Principal dimensions
H 26 mm
D 95 mm
d 60 mm
Speed ratings
Limiting speed 3800 r/min
Reference speed 2800 r/min
Company Information

SKF is the world's premier manufacturer of bearings and a vast range of other related products such as maintenance tools, seals, lubrication systems, linear motion products etc,. Marat Sp. z.o.o. is an Authorized Distributor and SKF Certified Maintenance Partner. Therefore, we take the authenticity and quality very seriously and ensure that all our bearings and related products are sourced directly from the manufacturer (SKF).

Orgional Car Clutch Thrust Industrial Ball Bearings 51212 Fast Delivery

Specification of thrust ball bearings

Own Brand

ZGJB

OEM Brand

According to your requirement

Product Name

thrust ball bearings

Series

thrust ball bearing 52220

Rings Material

Chrome steel-GCr15, high Carbon steel-GCR11,Stainless steel-440C,304 316

Cages Material

steel,brass,nylon thrust ball bearing 51212

ID size

10-400mm thrust ball bearing 51212

Quality standard

ISO9001:2000 thrust ball bearing 51212

Precsion

P0,P6,P5,P4 thrust ball bearing 51212

ABEC-1,ABEC-3,ABEC-5 etc. thrust ball bearing 51212

Clearance

C0,C1,C2,C3,C4,C5 thrust ball bearing 51212

Noise

Z1,Z2,Z3 thrust ball bearing 51212

Vibration

V1,V2,V3 thrust ball bearing 51212

HRC

58-65 thrust ball bearing 51212

Tolerance Grade

GB/T307.1-205 thrust ball bearing 51212

Delivery time

20-25 days thrust ball bearing 51212

Payment term

A:30% TT in advance,and balance against BL COPY

B: 100% LC AT SIGHT

Services

OEM,ODM,OBM Services

Packing

Single box,tube packing,industrial packing or according to customers' requirement

Main Market

Asia,Europe,America,Africa,Middle East,Australia etc.

51100 series and also can order according to your drawings:

Thurst bearing

Type

Old Code

Boundary Dimensions(mm)

d

D

T

51106

8106

30

47

11

51107

8107

35

52

12

51108

8108

40

60

13

51109

8109

45

65

14

51110

8110

50

70

14

51111

8111

55

78

16

51112

8112

60

85

17

51113

8113

65

90

17

51114

8114

70

95

18

51115

8115

75

100

19

51116

8116

80

105

19

51117

8117

85

110

19

51118

8118

90

120

22
