Axial Needle Roller Cage needle thrust bearing AXK1528 with Washer AS1528
Axial Needle Roller Cage needle thrust bearing AXK1528 with Washer AS1528
Axial Needle Roller Cage needle thrust bearing AXK1528 with Washer AS1528
Axial Needle Roller Cage needle thrust bearing AXK1528 with Washer AS1528
Specifications
Brand Name :
GQZ or OEM
Model Number :
AXK1528
Certification :
ISO
Place of Origin :
China Jiangsu
MOQ :
1 pcs
Price :
negotiation
Payment Terms :
T/T or western Union or PayPal
Supply Ability :
3,000pcs per month
Delivery Time :
3 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden case for outer packing
Product Name :
AXK1528
ID :
15mm
OD :
85mm
Thickness :
2mm
Washer No.: :
AS1528
Direction :
Single direction
Cage :
steel
Stock :
30000 Sets
Description

Axial Needle Roller And Cage Assemblies AXK1528 with Washer AS1528

1. Specification:

Metric Series Inch series Introduction
AXK TC Thrust needle roller and cage assemblies, single cage
NTB NTA Thrust needle roller and cage assemblies, double cage
AXW Thrust needle roller bearings with centering
AX Thrust needle roller bearings with washer
K811,K812,K893,K874,K894 Thrust roller and cage assembly
GS811,812,893,874,894 Thrust race, outer surface grinding
WS811,812,893,874,894 Thrust shaft ring, the inner surface grinding
LS Thrust washers, economical, no grinding inner and outer surfaces
ZS Center washer

AS

 TWA,TWAB,TWC,TWD; Thrust washer
TRA,TRB,TRC,TRD Thrust washer

2. Feature:

(1) Thrust needle roller bearing

(2) with 2 piece washer per set

(3) Steel cage
(4) Competitive price

(5) Good qualtiy

(6) Rich stock

(7) Quick delivery

(8) Single direction

(9) 1 year's quality guarantee

3. Bearing Picture:

Axial Needle Roller Cage needle thrust bearing AXK1528 with Washer AS1528

Axial Needle Roller Cage needle thrust bearing AXK1528 with Washer AS1528

4. We also supply following needle roller bearings:

Shaft Diameter(mm) Bearing Type Boundary Dimensions(mm) Basic Load Rating(N) Limiting Speed(rpm) Weight(g)
Current Type Original Type d D B Dynamic Static Grease Oil
8 AXK0821 8 21 2 7100 13500 11000 4000 2
10 AXK1024 10 24 2 7800 24000 9500 3600 3
12 AXK1226 12 26 2 8200 26700 7200 3200 3
15 AXK1528 15 28 2 9500 33000 6500 3000 4
17 AXK1730 17 30 2 10200 36500 5500 2800 4
20 AXK2035 20 35 2 11000 43000 5000 2600 5
25 AXK2542 25 42 2 12500 538000 4500 2300 7
30 AXK3047 30 47 2 14000 656000 4100 2100 8
40 AXK4060+2AS 40 60 3 25000 1100000 3200 1900 16
45 AXK4565 45 65 3 25800 1250000 3000 1700 18
55 AXK5578 55 78 3 35000 1950000 2600 1500 28
60 AXK6085 60 85 3 38600 2400000 2500 1100 33
70 AXK7095 70 95 4 50000 2670000 2100 950 60
75 AXK75100 75 100 4 51000 2750000 1900 900 61
90 AXK90120 90 120 4 66000 4100000 1580 800 86
100 AXK100135 100 135 4 76000 5570000 1400 770 104
110 AXK110145 110 145 4 82000 6000000 1300 740 122
130 AXK130137 130 137 5
150 AXK150190 150 190 5 118000 9600000 950 580 232
160 AXK160200 160 200 5 125000 10000000 900 500 246
