Bearing steel IR 17X20X30.5 Cam Follower Bearing P0/P6/P5/P4/P2
Bearing steel IR 17X20X30.5 Cam Follower Bearing P0/P6/P5/P4/P2
Bearing steel IR 17X20X30.5 Cam Follower Bearing P0/P6/P5/P4/P2
Bearing steel IR 17X20X30.5 Cam Follower Bearing P0/P6/P5/P4/P2
Specifications
Brand Name :
TIMKEN / NSK / KOYO / INA
Model Number :
IR 17X20X30.5
MOQ :
1PCS
Price :
1 USD
Payment Terms :
T/T, Western Union
Supply Ability :
10000PCS/Month
Delivery Time :
5 working days
Packaging Details :
Single packing + standard export packing
Bearing type :
Needle Roller Bearing
Material :
GCr15
Precision :
P0/P6/P5/P4/P2
Cage :
No
OEM :
Acceptable
Hardness :
60-65 HRC
Description

Needle roller bearing IR 17X20X30.5

1. Needle Roller Bearing Specification:

Bearing type Needle Roller Bearing
Model IR 17X20X30.5
Brand TIMKEN / NSK / KOYO / INA
Size (mm) 17X20X30.5
Weight (kg) 35 g
Lubrication Oil / Grease

2 . Description

Needle bearings are a bearing that is classified as either radial or thrust depending on the direction of the load being supported. Needle roller bearings include bearings whose rollers slightly exceed the size range of needle rollers as stipulated by ISO. Needle roller bearings include drawn cup and solid radial bearings, as well as application-specific cam followers, and roller followers. Thrust bearings include thrust needle bearings.

3.Types of Designs:

This kind of bearing has multiple structural styles for the choice of customers,such as narrow & broad series,with or without inner rings,cages,rib or sealings. It can be designed according to the special structural requirements of customers as well.

Product Precision Accuracy:

Dimensional tolerance and geometrical accuracy is based on GB/T5801.

Mutual difference of needle roller diameter is 2 um,and the precision grade is class G2(ISO GB/T309)

The diameter of inscribed circle conforms to tolerance grade F6 before the fitting of outer ring with cage and roller assembly.

4 . We also offer following Needle roller bearing .

Bearing Code. Boundary Dimensions
Current Code. Original Code Fw D C
mm
HK0306TN 3 6.5 6
BK0306TN 3 6.5 6
HK0408TN 37941/4 4 8 8
BK0408TN 57941/4 4 8 8
HK0509TN 47941/5 5 11 9
BK0509 45941/5 5 9 9
HK0608 37941/6 6 10 8
HK0609 47941/6 6 10 8
BK0609 45941/6 6 10 9
HK0708 7 11 8
HK0709 47941/7 7 11 8
BK0709 45941/7 7 11 9
HK0808 37941/8 8 12 8
BK0808 35941/8 8 12 8
HK0810 57941/8 8 12 8
BK0810 88941/8 8 12 10
HK08*14*10 27942/8 8 14 10
HK08*14*12 37942/8 8 14 12
HK0910 57941/9 9 13 8
BK0910 55941/9 9 13 10
HK0912 67941/9 9 13 12
HK1010 57941/10 10 14 10
BK1010 55941/10 10 14 10
HK1012 67941/10 10 14 12
BK1012 65941/10 10 14 12

Bearing steel IR 17X20X30.5 Cam Follower Bearing P0/P6/P5/P4/P2

Bearing steel IR 17X20X30.5 Cam Follower Bearing P0/P6/P5/P4/P2
