NU 2306 E ABEC-5 bearing cylindrical roller brass / steel cage
NU 2306 E ABEC-5 bearing cylindrical roller brass / steel cage
NU 2306 E ABEC-5 bearing cylindrical roller brass / steel cage
NU 2306 E ABEC-5 bearing cylindrical roller brass / steel cage
Specifications
Brand Name :
FAG / GQZ / AAA
Model Number :
NU 2306 E
Certification :
ISO 9001
MOQ :
1
Price :
1 USD
Payment Terms :
T/T, Western Union
Supply Ability :
1000 pcs / month
Packaging Details :
single packing + standard export packing
Bearing type :
Cylindrical Roller Bearing
Cage Material :
brass cage / steel cage
ID :
30 mm
OD :
72 mm
Clearance :
C0,C2,C3,C4,C5
Precision Level :
P0,P6,P5,P4,P2
Description

NU 2306 E ABEC-5 bearing cylindrical roller brass / steel cage

1. Cylindrical Roller Bearing Specification :

Bearing type Cylindrical Roller Bearing
Bearing Model NU 2306 E
Brand FAG / GQZ / AAA
Size (mm) 30 *72*27
MOQ 1 pcs
Stock Enough
Lubrication Oil
Application Automobiles, Rolling Mill, Mining, Metallurgy


2. Product Description :

single row cylindrical roller bearings, mainly of the NU, N, NJ and NUP designs
high-capacity cylindrical roller bearings, NCF , NJF and NUH design
double row cylindrical roller bearings, NNU , NN and NNUP designs
multi-row cylindrical roller bearings
single row full complement cylindrical roller bearings, NCF and NJG designs
double row full complement cylindrical roller bearings, NNCL NNCF, NNC and NNF designs
multi-row full complement cylindrical roller bearings, with four or eight rows of rollers
split cylindrical roller bearings



3. Advantage :

1> manufacturer & exporter
2> competitive price
3>high quality material
4> advanced machine
5> Strictly QC system
6> experienced engineers and workers, good service
7> low noise and long usage life
8> professional management and team

4 Features:


Up to 50% less frictional torque.
A significantly higher axial load carrying capacity can be achieved.
Longer operating life.
Low bearing temperature.
Reduced contact pressure
No wear on the roller and faces.

5 .Shipping:


1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )

6. APPLICATION:

Mainly used in large and medium-sized motor, locomotives, spindle, internal combustion
engines, generators, gas turbines, reducer, rolling mill, vibrating screen and lifting transportation machinery, etc

7 . We have enough stock , following is our products in stock .

Designations Old spec Principal Dimensions (mm) Speed ratings (rpm) Weight(kg)
d D B Fw Grease Oil
NU 303 E 32303 E 17 47 14 24.2 14000 17000 0.12
NU 304 E 32304 E 20 52 15 27.5 12000 15000 0.15
NU 304 32304 20 52 15 28.5 12000 15000 0.15
NU 305 E 32305 E 25 62 17 34 9500 12000 0.24
NU 305 32305 25 62 17 35 9500 12000 0.24
NU 306 E 32306 E 30 72 19 40.5 9000 11000 0.36
NU 306 32306 30 72 19 42 9000 11000 0.36
NU 307 E 32307 E 35 80 21 46.2 8000 9500 0.48
NU 307 32307 35 80 21 46.2 8000 9500 0.48
NU 308 E 32308 E 40 90 23 52 6700 8000 0.65
NU 308 32308 40 90 23 53.5 6700 8000 0.65
NU 309 E 32309 E 45 100 25 58.5 6300 7500 0.9
NU 309 32309 45 100 25 58.5 6300 7500 0.9
NU 310 E 32310 E 50 110 27 65 5000 6000 1.15
NU 310 32310 50 110 27 65 5000 6000 1.15
NU 311 E 32311 E 55 120 29 70.5 4800 5600 1.45
NU 311 32311 55 120 29 70.5 4800 5600 1.45
NU 312 E 32312 E 60 130 31 77 4300 5000 1.8
NU 312 32312 60 130 31 77 4300 5000 1.8
NU 313 E 32313 E 65 140 33 82.5 4000 4800 2.25
NU 313 32313 65 140 33 83.5 4000 4800 2.25
NU 2214 E 32314 E 70 150 35 89 3600 4300 2.75
NU 2214 32314 70 150 35 90 3600 4300 2.75
NU 315 E 32315 E 75 160 37 95 3400 4000 3.3
NU 315 32315 75 160 37 95.5 3400 4000 3.3
NU 316 E 32316 E 80 170 39 101 3200 3800 3.95
NU 316 32316 80 170 39 108 3200 3800 3.95
NU 2304 E 32604 E 20 52 21 27.5 11000 14000 0.21
NU 2304 32604 20 52 21 28.5 11000 14000 0.21
NU 2305 E 32605 E 25 62 24 34 9000 11000 0.35
NU 2305 32605 25 62 24 35 9000 11000 0.35
NU 2306 E 32606 E 30 72 27 40.5 8000 9500 0.53
NU 2306 32606 30 72 27 42 8000 9500 0.53
NU 2307 E 32607 E 35 80 31 46.2 7000 8500 0.72

NU 2306 E ABEC-5 bearing cylindrical roller brass / steel cage

NU 2306 E ABEC-5 bearing cylindrical roller brass / steel cage
