FAG NJ2207E.M1A .C4 Cylindrical Roller Bearing steel high speed
FAG NJ2207E.M1A .C4 Cylindrical Roller Bearing steel high speed
FAG NJ2207E.M1A .C4 Cylindrical Roller Bearing steel high speed
FAG NJ2207E.M1A .C4 Cylindrical Roller Bearing steel high speed
FAG NJ2207E.M1A .C4 Cylindrical Roller Bearing steel high speed
FAG NJ2207E.M1A .C4 Cylindrical Roller Bearing steel high speed
Specifications
Brand Name :
GQZ / AAA
Model Number :
NJ2207E.M1A .C4
Certification :
ISO 9001
MOQ :
1
Price :
1 USD
Payment Terms :
T/T, Western Union
Supply Ability :
1000 pcs / month
Packaging Details :
single packing + standard export packing
Bearing type :
Cylindrical Roller Bearing
Delivery :
Stock
Vibration Level :
Z1V1,Z2V2,Z3V3
Hardness :
HRC60~ HRC65
Load Direction :
Radial Bearing
Material :
GCr15
Description

FAG NJ2207E.M1A .C4 Cylindrical Roller Bearing steel high speed

1. Cylindrical Roller Bearing Specification :

Bearing type Cylindrical Roller Bearing
Bearing Model NJ2207E.M1A .C4
Brand GQZ / AAA
Size (mm) 35*72*23
MOQ 10 pcs
Stock Enough
Lubrication Oil
Application Automobiles, Rolling Mill, Mining, Metallurgy


2. Product Description :

Roller Bearings, Cylindrical Bearing

In bearings of this type, the cylindrical rollers are in linear contact with the raceways. They have a high radial load capacity and are suitable for high speeds.

There are different types designated as NU, NJ, NUP, N, NF (for single-row bearings), NNU, and NN (for double-row bearings depending on the design or absence of side ribs).

We supply these type: NU/NJ/NUP/N/NJ+HJ/NF/NN/NN K/NNU/NNU K/NN K

The outer and inner rings of all types are separable.

Some cylindrical roller bearings have no ribs on either the inner or outer ring, so the rings can move axially relative to each other. These can be used as free-end bearings. Cylindrical roller bearings, in which either

The inner or outer rings has two ribs and the other ring has one, are capable of taking some axial load in one direction Double-row cylindrical roller bearings have high radial rigidity and are used primarily for precision machine tools.


3. Features :

1. Long-life operation
2. Suitable for the radial and axial loaded
3. With low and smoothly coefficient of friction and without stick-slip effects
4. Suitable for dirty, corrosion, impact load and edge loading
5. The base material provided a good shock-absorbing capacity

4. APPLICATION:

Mainly used in large and medium-sized motor, locomotives, spindle, internal combustion
engines, generators, gas turbines, reducer, rolling mill, vibrating screen and lifting transportation machinery, etc

5 . We have enough stock , following is our products in stock .

Designations Old spec Principal Dimensions (mm) Speed ratings (rpm) Weight(kg)
d D B Fw Grease Oil
NU 1005 32105 25 47 12 30.5 11000 15000 0.1
NU 1006 32106 30 55 13 36.5 9500 12000 0.12
NU 1007 32107 35 62 14 42 8500 11000 0.16
NU 1008 32108 40 68 15 47 7500 9500 0.22
NU 1009 32109 45 75 16 52.5 6500 8500 0.26
NU 1010 32110 50 80 17 57.5 6300 8000 0.3
NU 1011 32111 55 90 18 64.5 5600 7000 0.45
NU 1012 32112 60 95 18 69.5 5300 6700 0.48
NU 1013 32113 65 100 18 74.5 4800 6000 0.51
NU 1014 32114 70 110 20 80 4800 6000 0.71
NU 1015 32115 75 115 20 85 4300 5600 0.74
NU 202 E 32202 E 15 35 11 19.3 18000 22000 0.047
NU 202 32202 15 35 11 19.3 15000 19000 0.047
NU 203 E 32203 E 17 40 12 22.1 16000 19000 0.068
NU 203 32203 17 40 12 22.9 14000 18000 0.068
NU 204 E 32204 E 20 47 14 26.5 13000 16000 0.11
NU 204 32204 20 47 14 27 13000 16000 0.11
NU 205 E 32205 E 25 52 15 31.5 11000 14000 0.13
NU 205 32205 25 52 15 32 11000 14000 0.13
NU 206 E 32206 E 30 62 16 37.5 9500 12000 0.2
NU 206 32206 30 62 16 38.5 9500 12000 0.2
NU 207 E 32207 E 35 72 17 44 8500 10000 0.3
NU 207 32207 35 72 17 43.8 8500 10000 0.3
NU 208 E 32208 E 40 80 18 49.5 7500 9000 0.37
NU 208 32208 40 80 18 50 7500 9000 0.37
NU 209 E 32209 E 45 85 19 54.5 6700 8000 0.43
NU 209 32209 45 85 19 55 6700 8000 0.43
NU 210 E 32210 E 50 90 20 59.5 6300 7500 0.48
NU 210 33210 50 90 20 60.4 6300 7500 0.48
NU 211 E 33211 E 55 100 21 66 6000 7000 0.66
NU 211 33211 55 100 21 66.5 6000 7000 0.66
NU 212E 33212 E 60 110 22 72 5300 6300 0.81
NU 212 33212 60 110 22 73 5300 6300 0.81
NU 213 E 33213 E 65 120 23 78.5 4800 5600 1.05
