140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device
140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device
140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device
140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device
140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device
140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device
Specifications
Brand Name :
SKF
Model Number :
H3032
Certification :
ISO9001:2008
Place of Origin :
Sweden
MOQ :
1 pcs
Price :
negotiation
Payment Terms :
T/T or western Union or PayPal
Supply Ability :
3,000pcs per month
Delivery Time :
3 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden case for outer packing
Product Name :
H3032
Shaft diameter :
140 mm
OD :
160 mm
Width :
93 mm
Material :
Gcr15
Type :
Metric series adapter sleeve
Lubrication :
oil or grease
Lead time :
within 3 days
Description

140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device

1. Specification:

Bearing No. H3032
Type Adapter sleeve
ID 140 mm
OD 160 mm
Height 93 mm

2. Feature:

(1) Single row

(2) With locking nut

(3) chrome steel material

(4) Sweden origin

(5) Competitive price

(6) Fast delivery

3. Bearing Picture:

140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device

140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device

140mm Shaft Using SKF H3032 Adapter Sleeve with Lock Nut and Locking Device

4. We also supply following adapter sleeves:

Dimensions Abutment dimensions Designations
d1(mm) D(mm) B(mm) da Max db Min Ba Min Mass(kg) Designations Adapter sleeve
17 47 14 28,5 23 5 0,16 1204 EKTN9 H 204
20 52 15 33 28 5 0,21 1205 EKTN9 H 205
20 52 18 31 28 5 0,23 2205 E-2RS1KTN9 H 305E
20 52 18 32 28 5 0,23 2205 EKTN9 H 305
20 62 24 35,5 29 5 0,42 2305 EKTN9 H 2305
25 62 16 40 33 5 0,32 1206 EKTN93) H 206
25 62 20 36,5 33 5 0,36 2206 E-2RS1KTN9 H 306E
25 62 20 38 33 5 0,36 2206 EKTN9 H 306
25 72 27 40 35 5 0,62 2306 E-2RS1KTN9 H 2306
30 72 17 47 38 5 0,44 1207 EKTN93) H 207
30 72 23 42,5 39 5 0,55 2207 E-2RS1KTN9 H 307E
30 72 23 45 39 5 0,54 2207 EKTN9 H 307
30 80 31 43,5 40 5 0,86 2307 E-2RS1KTN9 H 2307E
30 80 31 46 40 5 0,84 2307 EKTN9 H 2307
35 80 18 53 43 6 0,58 1208 EKTN93) H 208
35 80 23 49 44 6 0,67 2208 E-2RS1KTN9 H 308E
35 90 23 61 44 6 0,85 1308 EKTN9 H 308
35 90 33 55 45 6 1,2 2308 E-2RS1KTN9 H 2308
40 85 19 57 48 6 0,68 1209 EKTN93) H 209
40 85 23 53 50 8 0,76 2209 E-2RS1KTN9 H 309E
40 85 23 55 50 8 0,78 2209 EKTN9 H 309
40 100 36 60 50 6 1,4 2309 EKTN9 H 2309
45 90 20 62 53 6 0,77 1210 EKTN93) H 210
45 90 23 58 55 10 0,84 2210 E-2RS1KTN9 H 310E
45 110 27 70 55 6 1,45 1310 EKTN9 H 310
45 110 40 65 56 6 1,9 2310K H 2310
50 100 21 70 60 7 0,99 1211 EKTN93) H 211
50 100 25 65,5 60 11 1,1 2211 E-2RS1KTN9 H 311E
50 100 25 67 60 11 1,15 2211 EKTN9 H 311
50 120 43 72 61 7 2,4 2311K H 2311

If you want to buy this bearing,just send email directly to tommy@gqbearing.com
