Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing
Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing
Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing
Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing
Specifications
Brand Name :
NSK/OEM
Model Number :
NN3026MBKRCC1P5
Certification :
ISO9001:2008
Place of Origin :
Japan
MOQ :
1 pcs
Price :
negotiation
Payment Terms :
T/T or western Union or PayPal
Supply Ability :
3,000pcs per month
Delivery Time :
3 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden case for outer packing
Structure :
Cylindrical
Type :
Roller
Material :
Chrome steel
Application :
Vibration machinary,CNC machine and so on
weight :
4.04kg
Cage :
Brass cage
Description

Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing​

Bearing name :bearing for CNC machine cylindrical roller bearing

Model : NN3026MBKRCC1P5

Size : 130*182*52 mm

Weight : 5.88 KG

Material : GCR-15

Precision : P5

Quality : ISO9001:2008 approved

OEM service: Offer

Types of cylindrical roller bearing:

.Single row cylindrical roller bearing: NU, NJ, NUP, NUB series

.Double row cylindrical roller bearings:NNU series

.Four row cylindrical roller bearing:FC series

.Single row full complement cylindrical roller bearing:SL18 series, SL 19 series

.Double row full complement cylindrical roller bearing

.SL01 series, SL02 series, SL18 series.

Bearing type Cage symbol Specification Available size
NN MB Roller guided machined brass cage

NN3005,NN3026-NN3040

NN3920-NN3956,NN4920-NN4940
TB Roller guided PPS resin cage NN3006-NN3024
NNU MB Roller guided machined brass cage NNU4920-NNU4940
N MR Roller guided machined brass cage N1006-N1028
TP Outer ring guided PEEK resin cage N1009-N1017

Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 design draft :

Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing

Cylindrical roller bearings NN3026MBKRCC1P5

Bearing number : NN3026MBKR

Size (mm) : 130x182x52

Brand : NSK

Bore Diameter (mm) : 130

Outer Diameter (mm) : 182

Width (mm) : 52

Bearing dimensions and specification in brand catalogue :

d - 130 mm

D - 200 mm

E - 182 mm

B - 52 mm

C - 52 mm

r min. - 2 mm

Weight - 5,88 Kg

Basic dynamic load rating (C) - 284 kN

Basic static load rating (C0) - 475 kN

(Grease) Lubrication Speed - 4 600 r/min

(Oil) Lubrication Speed - 5 500 r/min

Dimension

(mm)

 Weight (kg)

Rated load

( KN)

Limiting speed

(r/min)

 Type
d D B r min F E Cr Cor Grease oil
100 140 40 1.1 113 137 1.88 125 244 4300 5100 NNU4920
150 37 1.5 -- 146 245 4000 4800 NN3020
105 145 40 1.1 118 146 1.96 132 270 4100 4800 NNU4921
160 41 2 -- 2.96 192 310 3800 4100 NN3021
110 150 40 1.1 123 155 2.04 132 258 3900 4600 NNU4922
170 45 2 -- 3.76 226 365 3600 4300 NN3022
120 165 45 1.1 134.5 165 2.76 170 328 3600 4200 NNU4924
200 80 1.112 141 11 -- -- -- -- NNU4124
180 46 2 -- 4.1 232 390 3300 3900 NN3024
130 180 50 1.5 146 182 3.79 187 368 3300 3900 NNU4926
200 52 2 -- 6.04 284 475 3100 3600

NN3026

Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing

Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing

Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing

Import NSK precision spindle Cylindrical roller bearing NN3026MBKRCC1P5 NSK Cylindrical Roller Bearing
