3193/3120 Customized Tapered Cylindrical Roller Bearing , Rolling Mill Bearing
3193/3120 Customized Tapered Cylindrical Roller Bearing , Rolling Mill Bearing
Specifications
Brand Name :
TIMKEN
Model Number :
3193/3120
MOQ :
1
Price :
1 USD
Payment Terms :
T/T, Western Union
Supply Ability :
10000PCS/Month
Delivery Time :
5 working days
Packaging Details :
Single packing + standard export packing
Material :
Bearing Steel
Precision :
P0/P6/P5/P4/P2
Bearing type :
Cylindrical Roller Bearing
Number of row :
Single / double
Sample order :
Agree
Clearance :
C0 / C3/C4
Description

3193/3120 Customized Tapered Cylindrical Roller Bearing , Rolling Mill Bearing

1. Tapered Roller Bearing Specification:

Bearing type Tapered Roller Bearing
Bearing Model 3193/3120
Brand TIMKEN
Size (mm) 31.750*72.626*30.162
Weight (kg) 0.57 KG
Seal type Open
Lubrication Oil,Grease
Application Automobiles, Rolling Mill, Mining, Metallurgy

Descriptions of Taper Roller Bearing

Single row tapered roller bearing is the most basic and widely used tapered bearing. It consists of the cone assembly and the cup. It is usually fitted as one of an opposing pair. During equipment assembly, single row bearings can be set to the required clearance (endplay) ro preload condition to optimize performance.

Specification dimensions(mm) weight(kg)
d D T
1986/1932 25.400 58.738 19.050 0.24
M84249/M84210 25.400 59.530 23.368 0.32
15578/15523 25.400 60.325 19.842 0.27
15101/15243 25.400 61.912 19.050 0.29
15116/15245 30.112 62.000 19.050 0.26
17119/17244 30.162 62.000 16.002 0.23
M86643/M86610 30.162 68.262 22.225 0.41
3187/3120 30.162 72.626 30.162 0.59
2558/2523 30.163 69.850 23.812 0.46
15120/15245 30.213 62.000 19.050 0.26
14116/14283 30.226 72.085 22.385 0.44
M86648A/M86610 30.995 64.292 21.433 0.32
08125/08231 31.750 58.738 14.684 0.16
LM67048/10 31.750 59.131 15.875 0.17
15126/15245 31.750 62.000 19.05 0.25
2580/2520 31.750 66.421 25.400 0.39
02476/02420 31.750 68.262 22.225 0.38
M88046/10 31.750 68.262 22.225 0.40
23491/23420 31.750 68.262 26.988 0.49
14125A/14276 31.750 69.012 19.845 0.34
2582/2523 31.750 69.850 23.812 0.44
3193/3120 31.750 72.626 30.162 0.57
02876/02820 31.750 73.025 22.225 0.45
2879/2820 31.750 73.025 22.225 0.46
HM88542/HM88510 31.750 73.025 29.370 0.61
HH224346/HH224310D 114.3 212.725 142.875 20.9
HH224346NA/HH224310D 114.3 212.725 142.875 21
HM926740/HM926710D 114.3 228.6 115.888 20.5
HH224349/HH224310D 114.976 212.725 142.875 20.8
M224748/M224710D 120 174.625 77.788 5.8
M224749/M224710D 120.65 174.625 77.788 5.7
795/792D 120.65 206.375 107.95 14
48286/48220D 123.825 182.562 85.725 7.4
95491/95927D 124.943 234.95 142.875 25.7
L225849/L225812D 127 169.975 58.738 3.45
48291/48992D 127 182.563 85.725 6.99
67388/67322D 127 192.85 101.6 11.1
67388/37323D 127 196.85 107.95 11.4
67388/67325D 127 200.025 101.6 11.7
