Slim Section Bearings Slewing Bearing with four point Four Point Contact
Slim Section Bearings Slewing Bearing with four point Four Point Contact
Slim Section Bearings Slewing Bearing with four point Four Point Contact
Slim Section Bearings Slewing Bearing with four point Four Point Contact
Specifications
Brand Name :
Optional
Model Number :
1787/600G
Certification :
ISO9001
Place of Origin :
Optional
MOQ :
1.PCS
Payment Terms :
T/T, Western Union, Paypal
Delivery Time :
Within 3 Working Days
Packaging Details :
Standard Carton Box / Wooden Pallet Case.
Stock :
180.pcs
Precision :
P0 , P6, P5 ,P4 ,P2
Material :
Bearing Steel ; Others
Operating Temp :
-25°C ~ +120°C
Type :
Four Point Contact Thin Section Ball
SIZE :
786*600*72mm
Description

Slim Section Bearings Slewing Bearing with four point Four Point Contact

Packaging & Delivery

Packaging Details: Inner packing: Single boxes or Industrial Package Outer packing: Solid cartons / pallets
Delivery Detail: within 2 weeks after deposit

Specifications

Slewing Bearing:
1) High quality and good service
2) Durable
3) ISO9001 certificate
4) OEM service is available

Slewing bearings is a kind of large-size bearing with special configuration which can bear axial load, radial load and tilting moment. Generally, a slewing bearing has mounting holes, lubricating holes and sealing system which can meet different needs of different machines under different working conditions.
Our slewing bearings include the following types:
4 point contact ball slewing bearing;
Double-row angular contact ball slewing bearing;
Crossed cylindrical roller slewing bearing;
Three-row cylindrical roller slewing bearing;
Ball and cylindrical roller combined slewing bearing.
These bearings can be divided with no-gear, external gear and internal gear.
Application: widely used in industries such as metallurgy,vessel oil,chemistry,mine coat,hydroelectric power,port machinery,heavy machinery and so on.
Bearing No. Boundary Dimension Mounting hold size Gear Data Basic Load Rating Mass
D d H D1 D2 n1 n2 φ1 φ2 m Da Z b x Coa Kg
D178794 694 470 77 630 500 18 18 M16 18 6 696 114 60 0 157 93.1
1787/600G 786 600 72 740 636 20 24 M18*2.5 19 6 789 131 50 0 107 94.1
1787/674G2 853 674 70 825 709 34 23 20 M20 7 889 125 50 0 183 89
1787/674G2K 853 674 70 825 709 34 24 18 18 7 889 125 50 0 179 88.6
1787/710G2 894 710 67 845 744 8 8 M10 M10 6 924 152 55 0 179 107
1787/710G2K 894 710 67 875 760 8 12 M12 M12 6 924 152 55 0 179 107
1787/710G2K1 894 710 67 865 744 20 20 13 13 6 924 152 55 0 215 107
1787/800G 4050 800 90 1012 838 30 30 20 20 6 1092 180 60 0 215 217
1787/800GK 4050 800 90 1012 838 30 30 20 20 6 1092 180 60 0 297 217
1787/1040G2 - 1040 80 1220 1080 30 30 M16 17.5 10 1314 125 70 0 501 251
1787/1060G 1335 1060 109 1295 1105 24 24 M20 22 10 1388 138 80 -1 463 407
1787/1075 1365 1075 120 1310 1130 36 36 26 26 8 1424 176 90 0 463 463
1787/1075K 1365 1075 130 1310 1130 36 36 24 24 10 1420 140 120 0 463 550
1787/1075G2 1365 1075 120 1310 1130 36 36 24 24 10 1425 138 90 1 463 463
1787/1075G2K 1365 1075 120 1310 1130 36 36 M24 26 8 1424 176 90 0 463 463
1787/1330G2 1475 1330 82.4 1510 1362 24 24 18.5 18.5 9 1584 174 70 0 353 280
1788/1410G2 1410 85 1590 1454 36 36 M16 17.5 10 1676 160 70 0 395 312
