X Type CSXU050-2RS Thin Section Bearing P5 P4 Precision 127x146.05x12.7 mm
X Type CSXU050-2RS Thin Section Bearing P5 P4 Precision 127x146.05x12.7 mm
X Type CSXU050-2RS Thin Section Bearing P5 P4 Precision 127x146.05x12.7 mm
X Type CSXU050-2RS Thin Section Bearing P5 P4 Precision 127x146.05x12.7 mm
X Type CSXU050-2RS Thin Section Bearing P5 P4 Precision 127x146.05x12.7 mm
X Type CSXU050-2RS Thin Section Bearing P5 P4 Precision 127x146.05x12.7 mm
Specifications
Brand Name :
Optional
Model Number :
CSXU050-2RS
Certification :
ISO9001
Place of Origin :
Optional
MOQ :
1.PCS
Payment Terms :
T/T, Western Union, Paypal
Delivery Time :
Within 3 Working Days
Packaging Details :
Standard Carton Box / Wooden Pallet Case.
Size :
127x146.05x12.7mm
Stock Qty :
220.pcs
Precision :
P6, P5 ,P4
Material :
Bearing Steel
Operating Temp :
-25°C ~ +120°C
Type :
X Type Four Point Contact Thin Section Ball
Description

X Type CSXU050-2RS Thin Section Bearing P5 P4 Precision 127x146.05x12.7 mm

BearingModel CSXU050-2RS
Material Bearing Steel GCr15 ; Others
Type Four Point Contact Thin Section Ball Bearing
d (mm) 127
D (mm) 146.05
B (mm) 12.7
Mass (KG) 0.31
Precision

P0, P6, P5 ,P4 ,P2

We currently have 220.pcs of CSXU050-2RS Four Point Contact Thin Section Ball Bearing In Stock.If you are in need of CSXU050-2RS Bearing,just feel free to contact us.We can assure you the best quality; the most competitive prices; the shortest delivery time and the highest quality service.

For more details of CSXU050-2RS ,please feel free to contact me by WhatsApp or SKYPE or E-mail.

Besides,we also have Various Kinds of other Bearings & Guide Blocks In Stock,just click the " Contact Now "button for Price & other Information.

Bearing

Model

d

mm

d

inch

D

mm

B

mm

Bearing

Model

d

mm

d

inch

D

mm

B

mm
CSXU040-2RS 101,6 4 120,65 12,7 CSCU040-2RS 101,6 4 120,65 12,7
CSXU045-2RS 114,3 4 1/2 133,35 12,7 CSCU045-2RS 114,3 4 1/2 133,35 12,7
CSXU050-2RS 127 5 146,05 12,7 CSCU050-2RS 127 5 146,05 12,7
CSXU055-2RS 139,7 5 1/2 158,75 12,7 CSCU055-2RS 139,7 5 1/2 158,75 12,7
CSXU060-2RS 152,4 6 171,45 12,7 CSCU060-2RS 152,4 6 171,45 12,7
CSXU065-2RS 165,1 6 1/2 184,15 12,7 CSCU065-2RS 165,1 6 1/2 184,15 12,7
CSXU070-2RS 177,8 7 196,85 12,7 CSCU070-2RS 177,8 7 196,85 12,7
CSXU075-2RS 190,5 7 1/2 209,55 12,7 CSCU075-2RS 190,5 7 1/2 209,55 12,7
CSXU080-2RS 203,2 8 222,25 12,7 CSCU080-2RS 203,2 8 222,25 12,7
CSXU090-2RS 228,6 9 247,65 12,7 CSCU090-2RS 228,6 9 247,65 12,7
CSXU100-2RS 254 10 273,05 12,7 CSCU100-2RS 254 10 273,05 12,7
CSXU110-2RS 279,4 11 298,45 12,7 CSCU110-2RS 279,4 11 298,45 12,7

Bearing

Model

d

mm

d

inch

D

mm

B

mm

Bearing

Model

d

mm

d

inch

D

mm

B

mm
CSCG055 139,7 5 1/2 190,5 25,4 CSEA020 50,8 2 63,5 6,35
CSCG065 165,1 6 1/2 215,9 25,4 CSEA025 63,5 2 1/2 76,2 6,35
CSCG070 177,8 7 228,6 25,4 CSEA030 76,2 3 88,9 6,35
CSCG075 190,5 7 1/2 241,3 25,4 CSEA035 88,9 3 1/2 101,6 6,35
CSCG080 203,2 8 254 25,4 CSEA040 101,6 4 114,3 6,35
CSCG090 228,6 9 279,4 25,4 CSEA045 114,3 4 1/2 127 6,35
CSCG100 254 10 304,8 25,4 CSEA047 120,65 4 3/4 133,35 6,35
CSCG120 304,8 12 355,6 25,4 CSEA050 127 5 139,7 6,35
CSCG140 355,6 14 406,4 25,4 CSEA055 139,7 5 1/2 152,4 6,35
CSCG160 406,4 16 457,2 25,4 CSEA060 152,4 6 165,1 6,35
CSCG180 457,2 18 508 25,4 CSEA065 165,1 6 1/2 177,8 6,35
CSCG200 508 20 558,8 25,4 CSEA070 177,8 7 190,5 6,35
CSCG250 635 25 685,8 25,4 CSEA075 190,5 7 1/2 203,2 6,35

Feature


Type : Thin section bearings CSXU ,Four point contact bearing, Type X, Sealed on both sides

Operating Temperatures : -25°C to +120°C

X Type CSXU050-2RS Thin Section Bearing P5 P4 Precision 127x146.05x12.7 mm

X Type CSXU050-2RS Thin Section Bearing P5 P4 Precision 127x146.05x12.7 mm
