Four Point Contact Thin Section Bearing CSXU055-2RS Sealed on both Sides 139.7x158.75x12.7 mm
Four Point Contact Thin Section Bearing CSXU055-2RS Sealed on both Sides 139.7x158.75x12.7 mm
Four Point Contact Thin Section Bearing CSXU055-2RS Sealed on both Sides 139.7x158.75x12.7 mm
Four Point Contact Thin Section Bearing CSXU055-2RS Sealed on both Sides 139.7x158.75x12.7 mm
Four Point Contact Thin Section Bearing CSXU055-2RS Sealed on both Sides 139.7x158.75x12.7 mm
Four Point Contact Thin Section Bearing CSXU055-2RS Sealed on both Sides 139.7x158.75x12.7 mm
Four Point Contact Thin Section Bearing CSXU055-2RS Sealed on both Sides 139.7x158.75x12.7 mm
Four Point Contact Thin Section Bearing CSXU055-2RS Sealed on both Sides 139.7x158.75x12.7 mm
Specifications
Brand Name :
Optional
Model Number :
CSXU055-2RS
Certification :
ISO9001
Place of Origin :
Optional
MOQ :
1.PCS
Payment Terms :
T/T, Western Union, Paypal
Delivery Time :
Within 3 Working Days
Packaging Details :
Standard Carton Box / Wooden Pallet Case.
Size :
139.7x158.75x12.7mm
Stock Qty :
180.pcs
Precision :
P0 , P6, P5 ,P4
Seal Type :
Sealed on Both Sides
Operating Temp :
-25°C ~ +120°C
Type :
Four Point Contact Thin Section Ball
Description

Four Point Contact Thin Section Bearing CSXU055-2RS Sealed on both Sides 139.7x158.75x12.7 mm

BearingModel CSXU055-2RS
Material Bearing Steel GCr15 ; Others
Type Four Point Contact Thin Section Ball Bearing
d (mm) 139.7
D (mm) 158.75
B (mm) 12.7
Mass (KG) 0.34
Precision

P0, P6, P5 ,P4 ,P2

We currently have 180.pcs of CSXU055-2RS Four Point Contact Thin Section Ball Bearing In Stock.If you are in need of CSXU055-2RS Bearing,just feel free to contact us.We can assure you the best quality; the most competitive prices; the shortest delivery time and the highest quality service.

For more details of CSXU055-2RS ,please feel free to contact me by WhatsApp or SKYPE or E-mail.

Besides,we also have Various Kinds of other Bearings & Guide Blocks In Stock,just click the " Contact Now "button for Price & other Information.

Feature


Type : Thin section bearings CSXU ,Four point contact bearing, Type X, Sealed on both sides

Operating Temperatures : -25°C to +120°C

Bearing

Model

d

mm

d

inch

D

mm

B

mm

Bearing

Model

d

mm

d

inch

D

mm

B

mm
CSXU040-2RS 101,6 4 120,65 12,7 CSCU040-2RS 101,6 4 120,65 12,7
CSXU045-2RS 114,3 4 1/2 133,35 12,7 CSCU045-2RS 114,3 4 1/2 133,35 12,7
CSXU050-2RS 127 5 146,05 12,7 CSCU050-2RS 127 5 146,05 12,7
CSXU055-2RS 139,7 5 1/2 158,75 12,7 CSCU055-2RS 139,7 5 1/2 158,75 12,7
CSXU060-2RS 152,4 6 171,45 12,7 CSCU060-2RS 152,4 6 171,45 12,7
CSXU065-2RS 165,1 6 1/2 184,15 12,7 CSCU065-2RS 165,1 6 1/2 184,15 12,7
CSXU070-2RS 177,8 7 196,85 12,7 CSCU070-2RS 177,8 7 196,85 12,7
CSXU075-2RS 190,5 7 1/2 209,55 12,7 CSCU075-2RS 190,5 7 1/2 209,55 12,7
CSXU080-2RS 203,2 8 222,25 12,7 CSCU080-2RS 203,2 8 222,25 12,7
CSXU090-2RS 228,6 9 247,65 12,7 CSCU090-2RS 228,6 9 247,65 12,7
CSXU100-2RS 254 10 273,05 12,7 CSCU100-2RS 254 10 273,05 12,7
CSXU110-2RS 279,4 11 298,45 12,7 CSCU110-2RS 279,4 11 298,45 12,7

Bearing

Model

d

mm

d

inch

D

mm

B

mm

Bearing

Model

d

mm

d

inch

D

mm

B

mm
CSEB020 50,8 2 66,675 7,938 CSEC040 101,6 4 120,65 9,525
CSEB025 63,5 2 1/2 79,375 7,938 CSEC045 114,3 4 1/2 133,35 9,525
CSEB030 76,2 3 92,075 7,938 CSEC047 120,65 4 3/4 139,7 9,525
CSEB035 88,9 3 1/2 104,775 7,938 CSEC050 127 5 146,05 9,525
CSEB040 101,6 4 117,475 7,938 CSEC055 139,7 5 1/2 158,75 9,525
CSEB042 107,95 4 1/4 123,825 7,938 CSEC060 152,4 6 171,45 9,525
CSEB045 114,3 4 1/2 130,175 7,938 CSEC070 177,8 7 196,85 9,525
CSEB055 139,7 5 1/2 155,575 7,938 CSED040 101,6 4 127 12,7
CSEB060 152,4 6 168,275 7,938 CSED045 114,3 4 1/2 139,7 12,7
CSEB065 165,1 6 1/2 180,975 7,938 CSED050 127 5 152,4 12,7
CSEF055 139,7 5 1/2 177,8 19,05 CSED055 139,7 5 1/2 165,1 12,7
CSEF060 152,4 6 190,5 19,05 CSED060 152,4 6 177,8 12,7
CSEF065 165,1 6 1/2 203,2 19,05 CSED065 165,1 6 1/2 190,5 12,7
CSEF070 177,8 7 215,9 19,05 CSED070 177,8 7 203,2 12,7
CSEF075 190,5 7 1/2 228,6 19,05 CSED080 203,2 8 228,6 12,7
CSEF080 203,2 8 241,3 19,05 CSED090 228,6 9 254 12,7
CSEF090 228,6 9 266,7 19,05 CSED100 254 10 279,4 12,7
CSEF100 254 10 292,1 19,05 CSED110 279,4 11 304,8 12,7
CSEF110 279,4 11 317,5 19,05 CSED120 304,8 12 330,2 12,7
CSEF120 304,8 12 342,9 19,05 CSED140 355,6 14 381 12,7
CSED160 406,4 16 431,8 12,7
CSED180 457,2 18 482,6

12,7

Four Point Contact Thin Section Bearing CSXU055-2RS Sealed on both Sides 139.7x158.75x12.7 mmFour Point Contact Thin Section Bearing CSXU055-2RS Sealed on both Sides 139.7x158.75x12.7 mm
