12.7mm Pitch 40MN 428H Motorbike Chain Nickel Plated ISO9001 stainless steel chain
12.7mm Pitch 40MN 428H Motorbike Chain Nickel Plated ISO9001 stainless steel chain
12.7mm Pitch 40MN 428H Motorbike Chain Nickel Plated ISO9001 stainless steel chain
12.7mm Pitch 40MN 428H Motorbike Chain Nickel Plated ISO9001 stainless steel chain
12.7mm Pitch 40MN 428H Motorbike Chain Nickel Plated ISO9001 stainless steel chain
12.7mm Pitch 40MN 428H Motorbike Chain Nickel Plated ISO9001 stainless steel chain
Specifications
Brand Name :
GQZ or OEM
Model Number :
428H
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1 box
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000000 meter per year
Delivery Time :
5-8 working days
Packaging Details :
individual packing box
Material :
40MN carbon steel or Nickel Plated
Pitch :
12.7 mm
Roller diameter :
8.51 mm
Description

12.7mm Pitch 40MN Carbon Steel High Stregth 428H Motorcycle Chain

1. Type: roller chain

2. Material:40MN carbon steel or nickle-plated

3. Application: motorcycles,bicycles and so on

4. Datasheet:

Chain number 428H
Pitch (P) 12.7 mm
Roller diameter (d1) 8.51 mm
Width between inner plates (b1) 7.85 mm
Pin diameter (d2) 4.45 mm
Inner plate depth (h2) 11.8 mm
Plate thickness (t) 2.03 mm

5. Feature:

Heat-treatment chain parts make chain durable

Competitive prices,our chain factory is established on 1999 year,have long time experience in producing roller chains

Great after-market service

OEM accptable,we have 20 years in manufacturing in standard and non-standard roller chains

6. Packing: plastic bag wraps the chain,outside with good quality individual carton box

7. Transportation type: by sea,by air,by express

8. Chain colors: steel color, black, golden and so on.

9. Chain photos:

12.7mm Pitch 40MN 428H Motorbike Chain Nickel Plated ISO9001 stainless steel chain

12.7mm Pitch 40MN 428H Motorbike Chain Nickel Plated ISO9001 stainless steel chain

10. We also supply following motorcycle chains:

Standard motorcycle chains such as 25H,219H,270H,420,420F3,420H,428,428H,428F1,428DS,520,520F2,

520F3,520H,525,525H,530,630

O-ring motorcycle chains such as 420OR,428HVS,50LD,520OR,520V6,520HOR,520HOR
