Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill
Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill
Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill
Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill
Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill
Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill
Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill
Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill
Specifications
Place of Origin :
Hunan, China
Model Number :
used for Retsch VIBRATORY DISC MILLRS 200
Brand Name :
kingda
Certification :
TUV
Price :
$1,699.00 - $1,899.00/pieces
Type :
Ceramic Parts
Application :
Industrial Ceramic
Material :
100ml tungsten carbide jar used for Retsch, 100% Virgin tungsten carbide
Processing Service :
Moulding
Name :
tungsten carbide ball mill jar used for Retsch RS 200,RS300
Size :
50ml,100ml,250ml,500ml
Grade :
YG6/YG8/YG15
Shape :
Cylinder,mortar grinding and grinding ringsRetsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mil
Surface :
Polishing
usage :
Size reduction, mixing, milling, dispersing,triturating
Quality :
European Standard
fit in machine :
Retsch VIBRATORY DISC MILLRS 200,RS300
Description

Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill

Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill

RETSCH Tungsten Carbide Comfort Grinding Jars:

With polished surface, highly wear-resistant and resistant to acid and alkali and high hardness, tungsten carbide ball mill jars can meet the vast majority of metal powder crushing and refining. Tungsten carbide ball mill jar is used as milling jar of planetary ball mill,virbratory disc mill matched with tungsten carbide balls, which is suitable for grinding materials in high hardness such as hard alloy powder, diamond powder, and silicon carbide powder, etc.

Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill

We have mass-produced various types of ball mill jars for Retsch and Fristch from Germany brand.

For Retsch grinding jar: 50ml,80ml,125ml tungsten carbide,agate, zirconium oxdie, alumina oxide, grinding jar for Retsch planetary bal mill PM100, PM100CM, PM200, PM 400; 25ml,35ml,50ml tungsten carbide,zirconia oxide jars for Retsch Mix mill MM 500; 50ml,100ml,250ml and 500ml tungsten carbide ,agate, zirconia oxide for Retsch vibratory disc ball mill RS200,RS300.

For Fritsch grinding jar: 250ml and 500ml agate,zirconia,alumina oxide, grinding jar for Fritsch P6.

We have inventory of all the above ball mill jars. Just let us talk more!

Physical Parameters:

Composition

%

Grade

Specific Gravity

g/cm3

Compression modulus Mpa

Hardness

HRA

Bending strength Mpa

Elasticity modulus Gpa

WC: 92%

Cobalt: 8%

YG8

≥14. 6

56

89. 0

≥2320

510.0

Dimesion for our regualar avaliable Tungsten carbide milling jars

Volume of Jar

External Diameter
(mm)

Inner Diameter
(mm)

Height of without lid

(mm)

Total Height
(mm)

50ml

49

38

52

56

100ml

63

51

59

63

250ml

86

73

69

75

500ml

104

90

96

103

1L

131

115

110

117

1.5L

131

115

172

181

2L

170

156

121

128

Remarks: Size deviation within ±1mm

Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill

Recommendation For Matching Solutions About Mill Jars & Materials
Categories of Materials Recommended Mill Jars
Soil and other Materials which are not allowed with any impurity Agate mill jar
Metal & nonmetal materials which are not allowed with any impurity Zirconia mill jar
High hardness materials like diamond, tungsten carbide Tungsten carbide mill jar
Strong add & alkali materials or other materials at high temperature PTFE mill jar
Iron ore materials with lower impurity sensitivity 304 Stainless steel mill jar
Pigment or other materials with later process under high temperature Nylon mill jar
Aluminum materials like ceramic glaze Corundum mill jar
Electronic materials like lithium battery Polyurethane mill jar
Easily oxidized materials or some special materials which need tobe protected under special atmosphere. Vacuum mill jar

Matching Solutions for Mill Jars & Balls
Items Agate Balls Alumina Balls Stainless Steel Balls Zirconia Balls Tungsten Carbide Balls
Agate Mill jar √
Corundum Mill Jar ▲ √ ▲
Stainless Steel Mill Jar √
Zirconia Mill Jar ▲ √
Nylon Mill Jar ▲ √
PTFE Mill Jar √ ▲
Polyurethane Mill Jar √ ▲
Tungsten Carbide Mill Jar ▲ √
√ means: most suitable ▲ means: suitable

Packaging & Shipping

Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill

Application Fields:

Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill

Retsch Grinding Jars 100ml Tungsten Carbide Ceramic Parts for disc mill
