Low Breakage Intermediate Diaphragm / Retention Ring Liners Cement Mill
Low Breakage Intermediate Diaphragm / Retention Ring Liners Cement Mill
Low Breakage Intermediate Diaphragm / Retention Ring Liners Cement Mill
Low Breakage Intermediate Diaphragm / Retention Ring Liners Cement Mill
Specifications
Place of Origin :
Jiangsu,China (Mainland)
Brand Name :
Chen’s Liner
Model Number :
DF035
Price :
Discuss in email
MOQ :
2tons
Port :
Shanghai
Packaging Details :
Packed by steel pallets.
Delivery Time :
It depends on the quantity to be ordered.
Payment Terms :
L/C,T/T
Supply Ability :
4500 Metric Ton/Metric Tons per Year
Certification :
ISO9001
Application :
Mining Industry
Material :
Iron
Dimensions :
As per drawings
Hardness :
More than HRC52
Product Name :
Ball Mill Liners
Type :
Ball Mill
Description

Low Breakage Intermediate Diaphragm / Retention Ring Liners Cement Mill

Summarization

High Cr white iron material possess a combination of superior abrasion resistance and a reasonable

degree of toughness. The high Cr castings have longer service life than the other material,such as

high Mn steel and Cr-Mo alloy steel.And now it is widely used in the working condition of high wear and low impact,such as dry grinding process,coal mills,cement mills due to its excellent performance.

Specification

Model Number DF035
Material High Cr Cast Iron
Hardness ≥HRC52
Dimension As per drawing
Process Sand Casting
Impact Value ≥AK 10J
Inspection

Dimensional Inspection

Chemical Composition Inspection

Hardness Inspection

UT Test
Application Coal Mill,Cement Mill,Mining Industry etc.
MOQ 2Tons
Delivery Time Depends on the quantity to be ordered.
Port Shanghai
Package Steel Pallets
Payment Terms T/T,L/C

Product Photo

Low Breakage Intermediate Diaphragm / Retention Ring Liners Cement Mill

Low Breakage Intermediate Diaphragm / Retention Ring Liners Cement Mill

Technical Parameters

Item High Cr White Iron High Cr Alloy Steel High Mn Steel Ni-hard Cast Iron
C 2.4-3.2 1.1-2.2 0.9-1.3 2.4-3.6
Si 0.6-1.2 0.6-1.2 ≤0.8 ≤0.8
Mn 0.5-1.0 0.5-1.0 11.0-18.0 ≤2.0
Cr 12.0-30.0 11.0-30.0 1.5-2.5 1.5-10
S ≤0.04 ≤0.04 ≤0.04 ≤0.15
P ≤0.06 ≤0.06 ≤0.06 ≤0.15
Mo 0.1-3.0 0.1-3.0 ≤1.0 ≤0.1
Cu 0.1-1.0 0.1-1.0 - -
Ni 0-0.3 0-0.3 - 3.3-10
Re - - - -
Equivalent
Specification		 GB/T8263-1999
AS2027 Cr27
AS2027 CrMo 15/3
AS2027 CrMo 20/2/1
ASTM A532 Class Ⅲ Type A 25%Cr
ASTM A532 Class Ⅱ Type B 15%Cr-Mo
BS 4844 3E
DIN1695
NFA32401		 GB/T5680-1998
DL/T 681-1999
JIS G 5153-1999
ASTM A128
DIN GX120Mn12
AFNORZ120Mn12		 GB/T8263-1999
AS2027/Ni-Cr1-550
AS2027/Ni-Cr2-500
AS2027/Ni-Cr4-500
AS2027/Ni-Cr4-600
AS2027/Ni-Cr4-630
ASTM A532 1-A,B,C,D
ASTM A532 2-A,B,C,D,E
ASTM A532 3-A
Material Type Martensite Matrix Austenitic Mn Steel -
Hardness HRC≥56 HB≤300 HRC≥56
Impact Value AK≥4J AK≥80J -
