Impact Value AK5-15J Cr-Mo Alloy Steel Mill Liner Bolts Hardness HRC33-42
Impact Value AK5-15J Cr-Mo Alloy Steel Mill Liner Bolts Hardness HRC33-42
Specifications
Place of Origin :
Jiangsu,China (Mainland)
Brand Name :
Chen’s Liner
Model Number :
DF033
MOQ :
3 Ton/Tons
Price :
Discuss in email
Packaging Details :
Packed by steel pallets.
Delivery Time :
It depends on the quantity to be ordered.
Payment Terms :
L/C,T/T
Supply Ability :
4500 Ton/Tons per Year
Port :
Shanghai
Certification :
ISO9001
Application :
Ball Mill,Coal Mill,Mine Mill
Material :
Cr-Mo Alloy Steel
Dimensions :
As per drawings
Hardness :
HRC33-42
Product Name :
Ball Mill Liners
Perfomance :
Better Toughness
Description

Impact Value AK5-15J Cr-Mo Alloy Steel Mill Liner Bolts Hardness HRC33-42

Summarization

Alloy Steel is our conventional material.We have supplied castings for Multotec,Mesto,CMC etc.

It posses excellent performances of high strength,toughness and longer service life.And it is widely used in AG Mill,SAG Mill and Ball Mill.

We applied resin sand the sodium silicate sand casting process.

Specification

Model Number DF033
Material Cr-Mo Alloy Steel
Hardness HRC33-42
Dimension As per drawing
Casting Process Sand Casting
Impact Value AK40-50J
Inspection

Dimensional Inspection

Chemical Composition Inspection

Hardness Inspection

UT Test
Application AG Mill,SAG Mill,Ball Mill,Mining Industry etc.
MOQ 3Tons
Delivery Time Depends on the quantity to be ordered.
Port Shanghai
Package Steel Pallets
Payment Terms T/T,L/C

Product Photo

Impact Value AK5-15J Cr-Mo Alloy Steel Mill Liner Bolts Hardness HRC33-42

Impact Value AK5-15J Cr-Mo Alloy Steel Mill Liner Bolts Hardness HRC33-42

Technical Parameters

Item Cr-Mo Alloy Steel Ⅰ Cr-Mo Alloy Steel Ⅱ Cr-Mo Alloy Steel Ⅲ
C 0.3-0.5 0.65-0.90 0.4-0.9
Si 0.15-1.20 ≤0.75 0.7-1.2
Mn 0.4-1.2 0.5-1.2 0.6-1.0
Cr 1.7-2.5 1.5-2.5 4.0-7.0
S ≤0.04 ≤0.06 ≤0.04
P ≤0.04 ≤0.06 ≤0.06
Mo ≤0.5 ≤0.5 ≤0.15
Cu 0.1-0.6 ≤0.25 0.2-0.4
Ni ≤0.5 ≤0.3 0-0.3
Re ≤0.02 ≤0.02 ≤0.02
Equivalent
Specification		 DL/T 681-1999
GB/T26651-2011		 AS2074L2B Mod DL/T 681-1999
Material Type Martensite Steel Martensite or Pearlitic Cr Mo Steel Martensite Steel
Hardness HRC≥48 HB470&HB321-370 HRC≥50
Impact Value AK≥40J - AK≥10J
