Specifications
Brand Name :
JINMA
Model Number :
Ball Mill Tile Grinder Bearing Grinder
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
US$ 2500-30000/piece
Payment Terms :
T/T
Delivery Time :
one month
Packaging Details :
Standard shipping packaging
type :
Ball Mill Tile Grinder Bearing Grinder
name :
Bearing Type Ball Mill
purpose :
for Mining Processing
Attributes :
Mining machine
Material :
Cement
Motor Type :
AC Motor
Motor Power :
475kw
Description

Rotary Dry 475kw Cement Ball Mills Machine Energy in Mining Process

Sell Well Ball Mill Sold to More Than 50 Countries

Ball Mill is a type of grinder used to grind materials into an extremely fine powder mainly for use in the mineral processing industry. Ball Mills can grind various ores and other materials.
Ball Mill is a key equipment to grind the crushed materials, which is widely used in the manufacturing industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics.

Name Rotary Dry 475kw Cement Ball Mills Machine Energy Saving
Power 475kw
Type Rotary Dry Ball Mills


Technical Specifications and Performance

Model(wet) Rotating speed of cylinder Input size(mm) Motor Power(Kw) Processing
Capacity(t/h)
      Tile Bearing
MQ1500*3000 33.3 <=20 95 80 8-10
MQ1500*6200 33.3 <=20   155 8-10
MQ1600*4500 29.8 <=20 130 130 7-14
MQ1830*4500 26.25 <=20 180 180 10-20
MQ1830*7000 26.25 <=20 245 245 10-20
MQ1830*10000 26.25 <=20   320 10-20
MQ2100*3000 24.6 <=20 210 210 15-25
MQ2100*4500 24.6 <=20 245 245 15-25
MQ2100*11000 24.6 <=20   570 15-25
MQ2200*7000 23.7 <=20   380 20-35
MQ2200*10000 23.7 <=20   500 20-35
MQ2400*4500 22.6 <=20 380 380 20-45
MQ2400*8000 22.6 <=20   475 20-45
MQ2400*10000 22.6 <=20   630 20-48
MQ2700*3600 21.4 <=20 475 380 25-50
MQ2700*10000 21.4 <=20   1000 25-50
MQ3200*6000 19.6 <=20   1000 30-60
MQ3200*8000 19.6 <=20   1400 30-60
MQ3600*4500 18.9 <=20   1250 35-82
MQ3600*6000 18.9 <=20   1400 35-82


Note: According to the hardness and thickness of the material, the handling capacity written above just for reference purposes only. (Refer to raw ore handling capacity)

The working principle
Ball mill mill is a kind of external teeth double bin horizontal drum mill. The material uniformly enters the first bin through the sleeve shaft in the feeding device. The first bin has stepped lining or corrugated lining, lined with steel balls of different specifications. The steel balls are brought to a certain height by the centrifugal force generated by the rotation of the drum and then fall down. As a result, it will give the material a heavy blow and play a grinding role. The crushed material from the first bin passes through a single layer separator into the second bin, which is lined with steel balls for further grinding. The grinding material is discharged through the discharge plate to complete the grinding process.
