Specifications
Brand Name :
Quectel
Model Number :
EM120R-GL
Place of Origin :
China
MOQ :
5
Payment Terms :
D/A, L/C, T/T, D/P, Western Union, MoneyGram
Delivery Time :
5-8 work days
Packaging Details :
42.0mm × 30.0mm × 2.3mm
LTE-FDD :
B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29①/B30/B32①/B66
LTE-TDD :
B38/B39/B40/B41/B42/B43/B46① (LAA)/B48 (CBRS)
DL 2CA :
Intra-band and Inter-band
DL 3CA :
Intra-band and Inter-band
DL 256QAM :
Supported
UL 2CA :
Intra-band
UL 64QAM :
Supported
WCDMA :
384 kbps (DL); 384 kbps (UL)
GNSS :
GPS/GLONASS/BeiDou(COMPASS)/Galileo
LTE :
600 Mbps (DL); 150 Mbps (UL)
DC-HSDPA :
42 Mbps (DL)
DC-HSUPA :
5.76Mbps (UL)
Description

Globe LTE-A EM120R-GL M.2 LTE Cat12 Modules

  • LTE Cat 12 module
  • 42.0mm × 30.0mm × 2.3mm
  • M.2 form factor
  • Max. downlink 600Mbps / 150Mbps uplink under LTE
  • Extended temperature range of -40°C to +85°C

  • Supports DFOTA
  • Supports DTMF
  • Supports MIMO
  • USB 2.0 high speed interface
  • Multi-constellation GNSS receiver

The EM120R-GL is an LTE-A category 12 module in an M.2 form factor designed in accordance with the 3GPP Release 14 specification which supports maximum downlink rates of 600Mbps and uplink rates of 150Mbps.

The EM120R-GL is designed for the global market and covers nearly all mainstream carriers worldwide. The module supports Qualcomm® IZat™ location technology Gen9 (GPS, GLONASS, BeiDou and Galileo) and integrated GNSS greatly simplifies product design and provides quicker, more accurate and more dependable positioning capability.

A rich set of internet protocols, industry-standard interfaces and abundant functionalities (PCIe interface/USB drivers for Windows, Linux, Android/built-in eSIM (optional) allow the module to serve a wide range of applications such as industrial routers, home gateways, STB, consumer and industrial laptops, industrial PDAs, rugged tablet PCs, and digital signage.
