BW200/4 Slurry Pump
BW200/4 Slurry Pump
Specifications
Brand Name :
BJB
Model Number :
BW200/4
Certification :
ISO
Place of Origin :
Baoji,China
MOQ :
10
Supply Ability :
100 sets in 3 months
Delivery Time :
20 days
Packaging Details :
Regular Export Package
Description

The model slurry pumps were designed and produced based on the former HTB slurry pumps to meet with well drilling needs of shadow, geology and underground water. The pump mainly matches the oil or water drilling rigs below 2000 meters and other drilling equipment with the same parameters. Driven by electric motors or diesel engines.It consists of an input device,a frame,a pump body,an air bag,a suction halter and a skid.

Technical specifications of BW200/4 mud pump

Type Horizontal duplex double action piston pump
Stroke(mm) 85
Pump speed(lpm) 145
Cylinder DN(mm) 80
Flow(L/min) 200
Discharge Pressure(MPa) 4
Power(kw) 15
Overall Dimension(mm) 1050*630*820
Weight(kg) 450

Application: Shallow oil field drilling, mining or coal mining.
