BSJ300L Roots Vacuum Booster Pump 1200 m³/h 3.7kW Good Geometrical Symmetry,vacuum pump
BSJ300L Roots Vacuum Booster Pump 1200 m³/h 3.7kW Good Geometrical Symmetry,vacuum pump
BSJ300L Roots Vacuum Booster Pump 1200 m³/h 3.7kW Good Geometrical Symmetry,vacuum pump
BSJ300L Roots Vacuum Booster Pump 1200 m³/h 3.7kW Good Geometrical Symmetry,vacuum pump
BSJ300L Roots Vacuum Booster Pump 1200 m³/h 3.7kW Good Geometrical Symmetry,vacuum pump
BSJ300L Roots Vacuum Booster Pump 1200 m³/h 3.7kW Good Geometrical Symmetry,vacuum pump
Specifications
Brand Name :
BSC
Model Number :
BSJ300L
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Payment Terms :
T/T
Supply Ability :
500 sets per month
Delivery Time :
5-30 days
Packaging Details :
wooden box
Surface :
Painting
Color :
Army Green
Pumping Rate :
1000 m³/h(16667L/min)
Material :
Aluminium alloy
Features :
Corrosion resistance
G.W. :
128kgs
N.W. :
115kgs
Meas. :
102*50*50cm
Description

1200 m³/h Army Green, 3.7kW Mechanical Booster Pump, Roots Pump BSJ300L

Description :

Roots vacuum pumps ,which are also called Roots blowers,are rotary plunger type pumps where two symmetrically shaped impellors rotate in opposite directions inside the pump housing.

Characteristics:

  • The use of oil-free intermediate seal, multiple sealed ways to ensure a high clean vacuum environment in the rotor chamber.
  • Advanced processing to ensure the good geometrical symmetry of the rotors, as well as low noise and long service life.
  • The whole rotors are made of aluminum alloy which has the characteristics of fast corrosion resistance and energy-efficient.

​Technical Parameter :

Model Units BSJ300L
Pumping Rate 50 Hz m³h-1 / Lmin-1 1000/16667
60 Hz 1200/20000
Max Inlet Pressure 50Hz Pa 1.3x103
60Hz Pa 1.1x103

Ultimate Vacuum

 Pa/ mbar

4×10-2
Motor Power kW(hp) 3.7 (5.0)
Inlet -- VG100
Outlet -- VF80
Cooling Method Water-cooled
Oil Need L 2.0
Ambient Temp. ℃ 5~40
Oil -- BSO-46

Note: The value of 'Ultimate Pressure' in this sheet is measured by Pirani gauge when the Baosi special pump oil is used, and the value should be 4x10-3 if the Mcleod gauge is used.

Performance Curve:

BSJ300L Roots Vacuum Booster Pump 1200 m³/h 3.7kW Good Geometrical Symmetry,vacuum pump

Dimensions:

BSJ300L Roots Vacuum Booster Pump 1200 m³/h 3.7kW Good Geometrical Symmetry,vacuum pump

BSJ300L Roots Vacuum Booster Pump 1200 m³/h 3.7kW Good Geometrical Symmetry,vacuum pump

Applications

  • Vacuum distillation
  • Vacuum packaging
  • Thin-film coating
  • Freeze drying
  • Electrical engineering
  • Printing
  • Surface treatment technique
  • Wind Energy
  • Ceramics and glasses

We provide you with individual support, we train you and we offer 24/7 service worldwide.
