BTO -22 Razor Barbed Wire With Post For Wire Mesh Fencing
BTO -22 Razor Barbed Wire With Post For Wire Mesh Fencing
BTO -22 Razor Barbed Wire With Post For Wire Mesh Fencing
BTO -22 Razor Barbed Wire With Post For Wire Mesh Fencing
BTO -22 Razor Barbed Wire With Post For Wire Mesh Fencing
BTO -22 Razor Barbed Wire With Post For Wire Mesh Fencing
Specifications
Brand Name :
Taiye
Model Number :
TG2
Certification :
ISO9001 ISO140001
Place of Origin :
Hebei,China
MOQ :
200 Square Meters
Payment Terms :
L/C, D/A, T/T, Western Union
Supply Ability :
100000 Square Meters per Week
Delivery Time :
Within 15 days or as your request
Packaging Details :
In bulk or on Pallet
Price :
To be negotiated
Name :
Hot Dipped Galvanized BTO-22 Razor Barbed Wire With Post For Wire Mesh Fencing
Material :
Hot Dipped Galvanized Razor Wire
Razor Wire Types :
BTO-12,18,28,30.CBT-60,65
Surface Treatment :
Hot dipped galvanized
Packing :
in bulk or on pallet
Technique :
Welded
Hole type :
Square or Diamond
Hole Size :
75*150mm,100*100mm,100*200mm,150*300mm or as your request
Description

Hot Dipped Galvanized BTO-22 Razor Barbed Wire With Post For Wire Mesh Fencing


Description

Welded razor wire mesh is also known as straight-line razor wire, is by the blade thorn rope straight welded together, is modified according to the welded wire mesh, main function is to guard against theft, climbing and isolation.

Material:

1.hot galvanized sheet and stainless steel sheet 304 316 and so on

2.Galvanized wire(Electro galvanized and hot dipped galvanized)

Specifications
Welded Razor Wire Mesh Hole Type
Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm
Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.

Welded Razor Wire Mesh Surface Treatment
Galvanized Coating:50-60g/m2 , 80-100g/m2 , 200-250g/m
Pvc Coated Color: green,red,white etc.

Welded Razor Wire Mesh Application
Welded razor wire is mainly used for garden apartment, office unit, railway, highway, industry, agriculture, forest protection, military field,prison isolati

Razor Blade Type And Spcification

Reference NumberThickness(mm)Wire Dia.(mm)Barb Length(mm)Barb Width(mm)Spacing(mm)
BTO-120.5±0.052.5±0.112±115±126±1
BTO-150.5±0.052.5±0.118±115±133±1
BTO-220.5±0.052.5±0.122±115±134±1
BTO-300.5±0.052.5±0.130±118±145±1
CBT-600.5±0.052.5±0.160±232±1100±2
CBT-650.5±0.052.5±0.165±221±1100±2


Panel Spcifications

Panel HeightPanel LengthBlade TypeMesh Hole(Square)Mesh Hole(Diamond)Square mesh with wire dia.
1.2m2-15mAll can be done50×10075×1504.0mm
1.5m2-15mAll can be done50×150150×3004.5mm
1.8m2-15mAll can be done75×150100×1005.0mm
2.0m2-15mAll can be done150×300100×200
2.1m2-15mAll can be done100×100
2.4m2-15mAll can be done100×150


Surface Treatment Type

  • Hot-dipped galvanized
  • Galvanized material then Powder coated
  • Galvanized material then Electrophoretic paint

The powder material from AKZONOBEL,Dupont,it can make strongly resist the corrosive and ultraviolet radiation.Doubld caoting layer make the fence long life more than 10years.

Suface TypeMinMax
Hot dipped galvanized50g/m2366g/m2
Powder coating60μm120μm


Color range:you can choose what color you request
Other colours are available on request.

Features

1 it is almost impossible to climb
2 high-strength steel core very difficult to cut off
3 powerful security fence barriers neat appearance
4 no secondary use, so he will not be stolen
5 extremely simple to install, needs three to four to install molding.

BTO -22 Razor Barbed Wire With Post For Wire Mesh Fencing

Our Advantage

  • Advance machine for this fence,PVC coated line,powder coating line
  • All part do in our factory,quality control and delivery time is best
  • If need,free design,free sample can be provide
  • We have injection machine to do the block by ourself
  • 18years factory,11years export experience

Trade Item

Delivery Terms :FOB, CIF
Payment Currency:USD, EUR, AUD,JPY, CAD, GBP, CNY
Payment Item:T/T, L/C, PayPal, Escrow
Nearest Port:Xingang port,Qingdao port
Delivery Time:General after 25days upon received T/T30% advance payment
Popular Payment detail: T/T 30% in advance as deposit, the balance against received the copy of B/L.

Product Tags: Razor barbed wire Razor Welded Mesh Fence
