BTC Barbed Tape Single Coil Galvanized Razor Wire Reinforced Concertinas
BTC Barbed Tape Single Coil Galvanized Razor Wire Reinforced Concertinas
BTC Barbed Tape Single Coil Galvanized Razor Wire Reinforced Concertinas
BTC Barbed Tape Single Coil Galvanized Razor Wire Reinforced Concertinas
Specifications
Brand Name :
Taiye
Model Number :
TZ26
Certification :
ISO9000
Place of Origin :
China
MOQ :
200 Rolls
Price :
To be negotiated
Payment Terms :
D/A, L/C, T/T, Western Union
Supply Ability :
50 Tons per week
Delivery Time :
Within 15 days or as your need
Packaging Details :
Waterproof Paper inside and woven bags outside
Product name :
BTC Barbed Tape Concertina Wire Single Coil Wire Reinforced Concertinas
Type :
Single
Specification :
BTO-22
Wire diameter :
2.5mm
Wire Material :
Hot dipped galvanized
Packing :
waterproof paper
Description

Single Coil Wire Reinforced Concertinas

BTC Barbed Tape Concertina Wire Single Coil Wire Reinforced Concertinas Single coil wire reinforced concertinas, 38″ in diameter are fabricated from 0.020″ thick ASTM A653 (GA) galvanized steel strip. Strip is clinched around a galvanized steel core wire. Each roll consists of 56 coil loops with pairs of coil loops alternately clipped together at five locations around the circumference. Each coil extends to 50′ when deployed at 21″ coil spacing. Two opposing handles at each end are attached to the end coils.

BTC Barbed Tape Concertina Wire Single Coil Wire Reinforced Concertinas Features & Benefits

  • Perimeter security products
  • Single coil wire-reinforced concertina
  • Standard configuration: short barb with galvanized tape and high tensile galvanized core (military BTC)
  • Refer to military specification A-A-55522A for additional information
  • Concertina barbed tape and core available in stainless steel

BTC Barbed Tape Concertina Wire Single Coil Wire Reinforced Concertinas Uses: Military battlefield and training barrier.

BTC Barbed Tape Concertina Wire Single Coil Wire Reinforced Concertinas

NSN DIAMETER COIL LOOPS STRIP MATERIAL CORE WIRE CLIPS LOOP SPACING YIELD
(in) (mm) (in) (mm) (ft) (m)
- 18 450 56 SS SS 3 16 406 37 11
- 18 450 56 SS GA 3 16 406 37 11
- 18 450 56 GA GA 3 16 406 37 11
- 28 720 56 SS SS 3 21 533 50 15
- 28 720 56 SS GA 3 21 533 50 15
- 28 720 56 GA GA 3 21 533 50 15
- 36 900 50 SS SS 5 24 600 50 15
- 36 900 50 SS GA 5 24 600 50 15
5660-00-921-5516 36 900 50 GA GA 5 24 600 50 15
- 38 965 56 SS SS 5 21 533 50 15
- 38 965 56 SS GA 5 21 533 50 15
- 38 965 56 GA GA 5 21 533 50 15
- 40 1000 56 SS SS 5 21 533 50 15
- 40 1000 56 SS GA 5 21 533 50 15
- 40 1000 56 GA GA 5 21 533 50 15

BTC Barbed Tape Concertina Wire Single Coil Wire Reinforced Concertinas Package: packed waterproof paper inside and woven bags outside, then compression. Perfect package avoid to be damaged and rust during the transportation.
Loading: (1) Neat piling without pallet (2) Pack in pallet (3) Special package with customers’ request
